Fan Assemblies
The fan assembly units in the SAN128B-6 chassis can be removed and replaced without special tools. The
device can continue operating during the replacement.
The device supports the following types of fan assemblies.
v Fan assembly with nonport-side air exhaust. This unit moves the air from the port-side to the
nonport-side of the device.
v Fan assembly with nonport-side air intake. This unit moves the air from the nonport-side to the
port-side of the device
Note: The three fan assemblies concurrently installed in the chassis must be of the same power type,
model (airflow direction), and part number. If the airflow directions are different, an error is generated on
the console.
Note: The fan assembly units are hot-swappable if they are replaced one at a time. They are identical and
fit into any fan slot.
1. Fan assembly unit handle
2. Captive screw
Figure 34. Fan assembly
© Copyright IBM Corp. 2018 65
