Symptom-to-FRU index
The symptom-to-FRU index in this section lists symptoms
and errors and their possible causes. The most likely
cause is listed first, in boldface type.
Note: Do the FRU replacement or other actions in the
sequence shown in the column headed “FRU or
action, in sequence.” If replacing a FRU does not
solve the problem, put the original part back in the
computer. Do not replace a nondefective FRU.
This index can also help you determine, during regular
servicing, what FRUs are likely to need to be replaced
next.
A numeric error is displayed for each error detected in
POST or system operation. In the displays, n can be any
number.
If no numeric code is displayed, check the narrative
descriptions of symptoms. If the symptom is not described
there, go to “Intermittent problems” on page 63.
Note
For an IBM device not supported by diagnostic
codes in the ThinkPad notebook computers, see the
manual for that device.
Numeric error codes
Symptom or error FRU or action, in sequence
0175
Bad CRC1, stop POST
task—The EEPROM checksum
is not correct.
System board.
0176
System Security—The system
has been tampered with.
1. Run IBM BIOS Setup
Utility, and save the
current setting by
pressing F10.
2. System board.
0177
Bad SVP data, stop POST
task—The checksum of the
supervisor password in the
EEPROM is not correct.
System board
Symptom-to-FRU index
ThinkPad T40, T40p, T41 Series 55

IBM ThinkPad T41 series Specifications

General

Operating System	Windows XP Professional
Weight	2.2 kg (4.9 lbs)
Chipset	Intel 855PM
Processor	Intel Pentium M
Display	14.1 inch
RAM	256 MB to 2 GB
Storage	30 GB to 80 GB HDD
Dimensions	311 x 255 x 26-30 mm
Display Resolution	1024x768 (XGA) or 1400x1050 (SXGA+)
Optical Drive	DVD-ROM, CD-RW/DVD-ROM Combo
Wireless	802.11b or 802.11g
Ethernet	10/100 Mbps
Battery	6-cell Li-Ion
Networking	Modem and Ethernet
Ports	2 USB 2.0, VGA, parallel, serial, infrared
Graphics	ATI Mobility Radeon 7500
Hard Drive Interface	Ultra ATA/100
