Ice I18B User Manual

ICE I18B/I18C

13
OPERATOR MANUAL
TECHNICAL SPECIFICATION
ITEM UNITS DATA
Working Width mm 450
Squeegee Width mm 780
Efciency m²/h 1100
Brush Dia. mm 450
Brush Speed rpm 180
Max Pad Pressure Kg 30
Brush Motor V / W
I18B: 24 / 550
I18C: 110 / 550
Vacuum Motor V / W
I18B: 24 / 500
I18C: 110 / 500
(GZZKXOKY

<'.&NX
2-12 / 85
Solution Tank Capacity L 35
Recovery Tank Capacity L 40
Machine Weight (without batteries) Kg 62.5
(GZZKXOKY=KOMNZ

Kg 2h25
Machine Length mm 1165
Machine Height mm 1025
Machine Width mm 520
)GHRK2KTMZN
m 25
Charger cord *
m 2
Max Gradient % 2
Type of Drive - Brush assisted
Noise Level dB 70
Working Vacuum mbar 155
*
ONLY FOR I18B
**
ONLY FOR I18C
