Ice i24BT Operator's & Parts Manual

15
ICE i20NB / i20NBT / i20NBT-OB / i24BT
PARTS LIST
RECOVERY TANK GROUP
DIA
NO.
PART
NUMBER
DESCRIPTION
NO
REQ'D
1 8111022 WARNING LABEL 1
2 8131002 RECOVERY TANK COVER 1
3 8131005 RECOVERY TANK COVER SEAL 1
4 1021616 HEX BOLT M6 X 16 12
5 1421618 FLAT WASHER M6×
∮
18×1.6 10
6 8111014 FLOAT ADAPTER 1
7 8111001 GASKET 1
8 8111015 FLOAT, SHUT-OFF 1
9 8131003 CAP 1
10 8131001 RECOVERY TANK 1
11 8131010 DRAIN HOSE 1
12 1962050 CLAMP 1
13 8111300 HINGE ASSEMBLY 2
14 8131020 CABLE 1
15 1421612 FLAT WASHER M6×
∮
12×1.6 2
16 8111024 LABEL, BATTERY INSTALLATION 1
17 4010316 ICE LOGO 1
18 8111008 BRACKET 1
19 1421816 FLAT WASHER M8×
∮
16×1.6 2
20 8111007 RECOVERY TANK SUPPORT 1
21 8115404 SLEEVE, P/M 1
22 1021830 HEX BOLT M8×30 1
23 8111016 PLATE 2
24 1221412 SCREW M4×12 2
