Ice i24BT Operator's & Parts Manual

19
ICE i20NB / i20NBT / i20NBT-OB / i24BT
PARTS LIST
SOLUTION TANK GROUP
DIA
NO.
PART
NUMBER
DESCRIPTION
NO
REQ'D
1 8113115 DOWN PRESSURE LABEL 1
2 8113101 DOWN PRESSURE LEVER BRACKET 1
3 1421816 FLAT WASHER M8×
∮
16×1.6 2
4 1422821 LOCK WASHER M8 2
5 1021820 HEX BOLT M8×20 2
6 8113104 BALL KNOB 1
7 8113106 DOWN PRESSURE LEVER 1
8 8113112 BUSHING 1
9 8113110 SLEEVE, P/M 1
10 8113111 NYLON FLAT WASHER
∮
12.9×
∮
25.4×0.8 2
11 8113109 THRUST BEARING 2
12 8113114 SPRING 1
13 8113107 RETAINER, SPRING 1
14 8113103 BOLT M6×18 1
15
8113108 LINK, SPRING 2
8133108 LINK, SPRING, ORBITAL HEAD MODEL 2
16 1123608 LOCK NUT M6 1
17 1221512 SCREW M5×12 15
18 1123507 LOCK NUT M5 1
19 8133113 SPRING 1
20 8133501 CARGO NET 1
21 8133502 CLAMP 4
22 1221412 SCREW M4X12 4
23 8133008 CLEAN TUBING 1
24 1962025 CLAMP 16-25mm 1
25 8133001 SOLUTION TANK 1
26 8119005 BALL VALVE, G1/2 1
27 8119007 ELBOW G1/2 1
28 8113021 HANDLE, CONNECTOR 1
29 8113020 CONNECTOR 2
30 8114731 BATTERY CONNECT CABLE, ASSEMBLY 1
31 8113013 SPACER, BATTERY 2
32
8113011 BATTERY, 12TB115, 115AH, HOPPECKE 2
8133010 BATTERY, 6-EVF-100, 110AH, CHILWEE 2
8133020 BATTERY, EV12A-A, 120AH, DISCOVER 2
