Ice i24BT Operator's & Parts Manual

17
ICE i20NB / i20NBT / i20NBT-OB / i24BT
PARTS LIST
VACUUM FAN GROUP
DIA
NO.
PART
NUMBER
DESCRIPTION
NO
REQ'D
1 8112005 GASKET, VACUUM MOTOR 1
2 1121605 HEX NUT M6 3
3 8112006 STUD M6×92 3
4
8132050 AMETEK VACUUM MOTOR , KIT, 24VDC 1
8132006 CARBON BRUSH, 24VDC VACUUM MOTOR 1
5 1421612 FLAT WASHER M6×
∮
12×1.6 7
6 1123608 LOCK NUT M6 3
7 8112003 BRACKET 1
8 1021616 HEX BOLT M6×16 4
9 8132007 MUFFLER, VACUUM MOTOR 1
10 1914300 TIE, NYLON, 5X300 2
11 8112001 CHARGER COVER 1
12 8118003 KNOB M8 1
13 8112004 BRACKET 1
