ICE RS26+ / RS32+ 13
OPERATOR MANUAL
TECHNICAL SPECIFICATIONS
MODELMODEL RS26+ RS32+
LENGTHLENGTH 63.4 in / 1,610 mm
WIDTH (MACHINE WITH WIDTH (MACHINE WITH
SCRUB HEAD)SCRUB HEAD)
33 in / 838 mm 36.5 in / 927 mm
HEIGHTHEIGHT 56.7 in / 1,440 mm
WEIGHTWEIGHT 618 lbs / 280 Kg 640 lbs / 290 Kg
WEIGHT WITH BATTERIESWEIGHT WITH BATTERIES 880 lbs / 400 Kg 900 lbs / 410 Kg
RECOVERY TANK CAPACITYRECOVERY TANK CAPACITY 27.7 Gal / 105 L
SOLUTION TANK CAPACITYSOLUTION TANK CAPACITY 28.5 Gal / 108 L
SQUEEGEE WIDTHSQUEEGEE WIDTH 33.8 in / 860 mm 40 in / 1,030 mm
CLEANING PATH WIDTHCLEANING PATH WIDTH 26 in / 650 mm 32 in / 810 mm
PRODUCTIVITY RATE PER PRODUCTIVITY RATE PER
HOUR (IN THEORY)HOUR (IN THEORY)
46, 300 ft
2
4,300 m
2
55, 600 ft
2
5,200 m
2
TRAVEL SPEED TRAVEL SPEED
(TRANSPORT)(TRANSPORT)
4 Mile / h
6.5 Km / h
MINIMUM AISLE TURNMINIMUM AISLE TURN 71 in / 1,800 mm 75 in / 1,900 mm
PAD/BRUSH PRESSUREPAD/BRUSH PRESSURE
80 lbs / 35 Kg
120 lbs / 55 Kg
160 lbs / 75 Kg
SOLUTION FLOWSOLUTION FLOW
0 ~ 0.7 Gal / Min
0 ~ 2.7 L / Min
BATTERIES 4 x 6V, 240AH@ 20Hr
VOLTAGEVOLTAGE 24V DC
DRIVE WHEELDRIVE WHEEL 1.1 hp / 0.8 KW
BRUSH MOTORBRUSH MOTOR (2) 0.6 hp / 0.45 KW, 210 RPM
VACUUM MOTORVACUUM MOTOR 0.6 hp / 0.45KW
VACUUM WATER LIFT (MAX)VACUUM WATER LIFT (MAX) 70 in. H2O / 1780 mm. H2O
RUN TIME PER CHARGERUN TIME PER CHARGE 3~3.5 Hours
DECIBEL RATING AT DECIBEL RATING AT
OPERATOR'S EAR, INDOORSOPERATOR'S EAR, INDOORS
68 dB(A)
GRADE LEVEL, MAXGRADE LEVEL, MAX Scrubbing: 4°/7% Transporting (empty):10°/17.5%
