Ice RS26+ User Manual

ICE RS26+ / RS32+ 15
OPERATOR MANUAL
MAIN FRAME GROUP
DIA
NO.
PART
NUMBER
DESCRIPTION
NO
REQ'D
1 8320150 MAIN FRAME, WELDED 1
2 8310133 RUBBER GROMMET 4
3
8310119 10" WHEEL, PU TIRE 2
1612605 BALL BEARING,6205-2RS 4
8315250 10" WHEEL, ANTI-SLIP, OPTION 2
4 1436025 RETAINING RING, 25MM 2
5 8310150 WHEEL CAP 2
6 1521410 SCREW, SOCKET, M4×10 2
7 1883207 BARRIER TERMINAL BLOCK 1
8 8310120 BRACKET, STAND 2
9 1421824 FLAT WASHER, M8×
∮
24×2.0 3
10 1422821 LOCK WASHER M8 3
11 1021825 BOLT, HEX, M8×25 3
12 8210118 STATIC STRAP 1
13 8310708A HORN, 24VDC, KIT 1
14 1421307 FLAT WASHER, M3×
∮
7×0.5 4
15 1221312 SCREW, PAN HEAD, M3×12 2
