S.=Surface mount
[VCO UNIT][VCO UNIT]
R29 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R30 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R31 7030003520 S.RESISTOR ERJ3GEYJ 472 V (4.7 kΩ)
R32 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R33 7030003210 S.RESISTOR ERJ3GEYJ 120 V (12 Ω)
R34 7030003280 S.RESISTOR ERJ3GEYJ 470 V (47 Ω)
R35 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R36 7030003430 S.RESISTOR ERJ3GEYJ 821 V (820 Ω)
R37 7030003320 S.RESISTOR ERJ3GEYJ 101 V (100 Ω)
R38 7030003210 S.RESISTOR ERJ3GEYJ 120 V (12 Ω)
R39 7030003330 S.RESISTOR ERJ3GEYJ 121 V (120 Ω)
R40 7030003520 S.RESISTOR ERJ3GEYJ 472 V (4.7 kΩ)
R41 7030003480 S.RESISTOR ERJ3GEYJ 222 V (2.2 kΩ)
R42 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R43 7030003470 S.RESISTOR ERJ3GEYJ 182 V (1.8 kΩ)
R44 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R45 7030003320 S.RESISTOR ERJ3GEYJ 101 V (100 Ω)
R46 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R47 7030003470 S.RESISTOR ERJ3GEYJ 182 V (1.8 kΩ)
R48 7030003520 S.RESISTOR ERJ3GEYJ 472 V (4.7 kΩ)
R49 7030003480 S.RESISTOR ERJ3GEYJ 222 V (2.2 kΩ)
R50 7030003460 S.RESISTOR ERJ3GEYJ 152 V (1.5 kΩ)
R51 7030004050 S.RESISTOR ERJ3GEYJ 1R0 V (1 Ω)
R52 7030003520 S.RESISTOR ERJ3GEYJ 472 V (4.7 kΩ)
R53 7030003330 S.RESISTOR ERJ3GEYJ 121 V (120 Ω)
R54 7030003480 S.RESISTOR ERJ3GEYJ 222 V (2.2 kΩ)
R55 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R56 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R57 7030003260 S.RESISTOR ERJ3GEYJ 330 V (33 Ω)
R58 7030003250 S.RESISTOR ERJ3GEYJ 270 V (27 Ω)
R59 7030003250 S.RESISTOR ERJ3GEYJ 270 V (27 Ω)
R60 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R61 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R62 7030003340 S.RESISTOR ERJ3GEYJ 151 V (150 Ω)
R63 7030003840 S.RESISTOR ERJ3GEYJ 225 V (2.2 MΩ)
C1 4030007090 S.CERAMIC C1608 CH 1H 470J-T
C2 4030006860 S.CERAMIC C1608 JB 1H 102K-T
C3 4030006860 S.CERAMIC C1608 JB 1H 102K-T
C4 4030007090 S.CERAMIC C1608 CH 1H 470J-T
C5 4030006860 S.CERAMIC C1608 JB 1H 102K-T
C6 4030006860 S.CERAMIC C1608 JB 1H 102K-T
C7 4030006860 S.CERAMIC C1608 JB 1H 102K-T
C8 4030007090 S.CERAMIC C1608 CH 1H 470J-T
C9 4030007090 S.CERAMIC C1608 CH 1H 470J-T
C10 4030006860 S.CERAMIC C1608 JB 1H 102K-T
C11 4030006860 S.CERAMIC C1608 JB 1H 102K-T
C12 4030006860 S.CERAMIC C1608 JB 1H 102K-T
C13 4030006900 S.CERAMIC C1608 JB 1H 103K-T
C14 4030006920 S.CERAMIC C1608 CH 1H 010C-T
C15 4030006860 S.CERAMIC C1608 JB 1H 102K-T
C16 4030007100 S.CERAMIC C1608 CH 1H 560J-T
C17 4030006950 S.CERAMIC C1608 CH 1H 040C-T
C18 4030017810 S.CERAMIC C1608 CH 1H 102J-T
C19 4030007060 S.CERAMIC C1608 CH 1H 270J-T
C20 4030008630 S.CERAMIC C1608 JF 1H 104Z-T
C21 4030007010 S.CERAMIC C1608 CH 1H 100D-T
C22 4030007010 S.CERAMIC C1608 CH 1H 100D-T
C23 4030006850 S.CERAMIC C1608 JB 1H 471K-T
C24 4030008630 S.CERAMIC C1608 JF 1H 104Z-T
C25 4030008920 S.CERAMIC C1608 JB 1H 473K-T
C26 4550000550 S.TANTALUM TESVA 1V 224M1-8L
C27 4030006860 S.CERAMIC C1608 JB 1H 102K-T
C28 4550002980 S.TANTALUM TEMSVA 1C 225M-8L
C29 4550000530 S.TANTALUM TESVA 1V 104M1-8L
C30 4030011600 S.CERAMIC C1608 JB 1E 104K-T
C31 4030006860 S.CERAMIC C1608 JB 1H 102K-T
C32 4030006860 S.CERAMIC C1608 JB 1H 102K-T
C33 4030006860 S.CERAMIC C1608 JB 1H 102K-T
C34 4030009570 S.CERAMIC C1608 CH 1H 0R3B-T
C35 4030006860 S.CERAMIC C1608 JB 1H 102K-T
C36 4030006860 S.CERAMIC C1608 JB 1H 102K-T
C37 4030007020 S.CERAMIC C1608 CH 1H 120J-T
C38 4030007050 S.CERAMIC C1608 CH 1H 220J-T
C39 4030007040 S.CERAMIC C1608 CH 1H 180J-T
C40 4030006920 S.CERAMIC C1608 CH 1H 010C-T
C41 4030006860 S.CERAMIC C1608 JB 1H 102K-T
C42 4030006860 S.CERAMIC C1608 JB 1H 102K-T
C43 4030006860 S.CERAMIC C1608 JB 1H 102K-T
C44 4030006860 S.CERAMIC C1608 JB 1H 102K-T
C45 4030006970 S.CERAMIC C1608 CH 1H 060D-T
C46 4030007020 S.CERAMIC C1608 CH 1H 120J-T
C47 4030007030 S.CERAMIC C1608 CH 1H 150J-T
C48 4030007040 S.CERAMIC C1608 CH 1H 180J-T
C49 4030006990 S.CERAMIC C1608 CH 1H 080D-T
C50 4030006860 S.CERAMIC C1608 JB 1H 102K-T
C51 4030006920 S.CERAMIC C1608 CH 1H 010C-T
C52 4030006970 S.CERAMIC C1608 CH 1H 060D-T
C53 4030007060 S.CERAMIC C1608 CH 1H 270J-T
C54 4030006970 S.CERAMIC C1608 CH 1H 060D-T
C55 4030007050 S.CERAMIC C1608 CH 1H 220J-T
C56 4030006860 S.CERAMIC C1608 JB 1H 102K-T
C57 4030006970 S.CERAMIC C1608 CH 1H 060D-T
C58 4030006980 S.CERAMIC C1608 CH 1H 070D-T
C59 4030007040 S.CERAMIC C1608 CH 1H 180J-T
C60 4030006910 S.CERAMIC C1608 CH 1H 0R5C-T
C61 4030006860 S.CERAMIC C1608 JB 1H 102K-T
C62 4030006950 S.CERAMIC C1608 CH 1H 040C-T
C63 4030007030 S.CERAMIC C1608 CH 1H 150J-T
C64 4030006860 S.CERAMIC C1608 JB 1H 102K-T
C65 4030006980 S.CERAMIC C1608 CH 1H 070D-T
C66 4030006860 S.CERAMIC C1608 JB 1H 102K-T
C67 4030007040 S.CERAMIC C1608 CH 1H 180J-T
C68 4030007090 S.CERAMIC C1608 CH 1H 470J-T
C69 4030006990 S.CERAMIC C1608 CH 1H 080D-T
C70 4030006860 S.CERAMIC C1608 JB 1H 102K-T
C71 4030006920 S.CERAMIC C1608 CH 1H 010C-T
C72 4030006860 S.CERAMIC C1608 JB 1H 102K-T
C73 4030006860 S.CERAMIC C1608 JB 1H 102K-T
C74 4030006860 S.CERAMIC C1608 JB 1H 102K-T
C75 4030006860 S.CERAMIC C1608 JB 1H 102K-T
C76 4030007090 S.CERAMIC C1608 CH 1H 470J-T
C77 4030006850 S.CERAMIC C1608 JB 1H 471K-T
C78 4030011600 S.CERAMIC C1608 JB 1E 104K-T
C79 4030007050 S.CERAMIC C1608 CH 1H 220J-T
C80 4030006940 S.CERAMIC C1608 CH 1H 030C-T
C81 4030006860 S.CERAMIC C1608 JB 1H 102K-T
C82 4030006860 S.CERAMIC C1608 JB 1H 102K-T
C83 4030006860 S.CERAMIC C1608 JB 1H 102K-T
C84 4030006860 S.CERAMIC C1608 JB 1H 102K-T
C85 4030006860 S.CERAMIC C1608 JB 1H 102K-T
C86 4030006860 S.CERAMIC C1608 JB 1H 102K-T
C87 4030007060 S.CERAMIC C1608 CH 1H 270J-T
C88 4030007100 S.CERAMIC C1608 CH 1H 560J-T
C89 4030007060 S.CERAMIC C1608 CH 1H 270J-T
J1 6510023410 CONNECTOR IMSA-9210B-1-06Z172-T
J2 6510023400 CONNECTOR IMSA-9210B-1-03Z172-T
J3 6510023400 CONNECTOR IMSA-9210B-1-03Z172-T
J4 6510023400 CONNECTOR IMSA-9210B-1-03Z172-T
J5 6510023410 CONNECTOR IMSA-9210B-1-06Z172-T
W1 7030003860 S.JUMPER ERJ3GE JPW V
W2 7030003860 S.JUMPER ERJ3GE JPW V
W3 7030003860 S.JUMPER ERJ3GE JPW V
W4 7030003860 S.JUMPER ERJ3GE JPW V
EP1 0910055402 PCB B 5844B
5 - 13
REF ORDER
DESCRIPTION
NO. NO.
REF ORDER
DESCRIPTION
NO. NO.
