Icom IC-703 Service Manual

SECTION 6 MECHANICAL PARTS AND DISASSEMBLY
6 - 1
J1 6510000370 Antenna connector MR-DS 1
W7 8900011980 Cable OPC-1214 1
W8 8900011980 Cable OPC-1214 1
W9 8900011970 Cable OPC-1213 1
EP1 880001250 DSP unit UT-106 [Equipped version] only 1
SP1 2510000990 Speaker VS-66Y0811 1
MP1 8010001490 Stand (D) 1
MP2 8930005790 Color foot (A) 1
MP3 8930005800 Color foot (B) 1
MP4 8820000530 Flange bolt M4 × 8 NI 1
MP5 8930042690 Rubber foot (L) 2
MP8 8930052450 2355 earth plate 1
MP9 8810008660 Screw PH BT M3 × 8 NI-ZU 9
MP10 8810008660 Screw PH BT M3 × 8 NI-ZU 2
MP11 8810009610 Screw FH M2.6 × 6 ZK 9
MP12 8850000140 Flat washer M4 NI BS 1
MP13 8810008990 Screw BT M2 × 10 ZK 1
MP14 8850001560 Ster washer M4 1
MP15 8810008660 Screw PH BT M3 × 8 NI-ZU 9
MP16 8810004430 Screw PH M3 × 6 ZK 2
MP17 8810004430 Screw PH M3 × 6 ZK 2
MP19 8810003380 Setscrew C M3 × 10 2
MP20 8810009610 Screw FH M2.6 × 6 ZK 9
MP21 8930042440 1897 SP holder 1
MP22 8810009610 Screw FH M2.6 × 6 ZK 4
MP23 8010019121 2591 chassis-1 1
MP24 8110007880 2591 L-cover 1
MP25 8110007940 2591 T-cover assembly 1
MP26 8930059121 Thermally sheet (AJ)-1 2
MP28 8930059971 2591 A-sponge-1 1
MP29 8930059961 2591 SP sponge-1 1
MP30 8930059880 Earth spring (H) 1
MP32 8810008660 Screw PH BT M3 × 8 NI-ZU 1
MP33 8510015060 2591 shield plate 1
MP35 8930060140 Sheet (CI) 1
MP36 8930060140 Sheet (CI) 1
MP38 8930060310 Shield tape (P) 1
MP39 8930060300 Shield tape (O) 1
MP40 8930060290 Shield tape (N) 1
[CHASSIS UNIT]
ORDER
NO.
REF.
NO.
DESCRIPTION QTY.
EP1 0880001360 EX-2500 #02 1
W1 8900006040 Flat cable OPC-593 1
W2 8900006251 Cable OPC-610A 1
MP1 8210019400 2177 front panel (A)-1 assembly 1
MP2 8210012580 1691 rear panel 1
MP3 8930058960 2177 menu key (A) 1
MP4 8930047960 2177 mode key 1
MP7 8930036751 Spring (Y)-1 1
MP9 8830001010 Hex nut (A) 2
MP10 8610010000 Knob N237 (incl. MP28) 1
MP11 8610010010 Knob N238 2
MP12 8610010112 Knob N239-2 assembly 1
MP15 8930036691 1691 release button-1 1
MP18 8310036273 1691 brake plate-3 (incl. MP20) 1
MP19 8950004192 1691 contact base (B)-2 1
MP20 8930036740 1691 brake pad 2
MP21 8930037111 1691 brake sheet-1 1
MP23 8810008990 Screw PH BT M2 × 10 ZK 2
MP24 8930038940 Sponge (EF) 1
MP26 8610010360 Knob N260 (incl. MP27) 1
MP27 8610007510 Knob spring No.7800 1
MP28 8610007510 Knob spring No.7800 1
[FRONT UNIT]
ORDER
NO.
REF.
NO.
DESCRIPTION QTY.
J2 6450001630 Connector HSJ1406-01-050 (PHONES) 1
DS4 5030001670 LCD DLC-8309YBGF 1
DS5 5030002560 LED CV1073 1
EP7 8930059720 LCD connector SRCN-2591-SP-N-W 2
MP1 8930036710 1691 LCD holder 1
MP2 8810009040 Setscrew H M2.6 × 10 NI 1
MP3 8830000180 Nut M2.6 NI BS 1
MP4 8510015220 2591 front plate 1
MP6 8510014100 2177 front shield 1
[DISPLAY BOARD]
ORDER
NO.
REF.
NO.
DESCRIPTION QTY.
