Icom IC-A16 Basic Manual

11
BASIC MANUAL
6
SPECIFICATIONS AND OPTIONS
■ Specications
L All stated specications are subject to change without notice or obligation.
D General
Frequency range: IC-A16
IC-A16E
TX
RX
WX
TX/RX
118.000 ~ 136.99166 MHz
108.000 ~ 136.99166 MHz
161.650 ~ 163.275 MHz
118.000 ~ 136.99166 MHz
Channel spacing: 25 kHz/8.33 kHz
Mode: IC-A16 6K00A3E/5K60A3E
16K0G3E (WX)
IC-A16E 6K80A3E/5K00A3E
Number of Memory channels: 200 Channels
Antenna impedance: 50 Ω nominal
Antenna connector: BNC type
Power supply requirement: 7.2 V DC standard
Current drain: Less than 1.8 A
Operating temperature range: IC-A16
IC-A16E
–10˚C ~ +60˚C, 14˚F ~ 140˚F
–20˚C ~ +55˚C
Dimensions*
1
: 52.2 (W) × 111.8 (H) × 34.1 (D) mm,
2.1 (W) × 4.4 (H) × 1.3 (D) inches
Weight (approximately): 257 g, 9.1 oz with BP-280
D Transmitter
Output power: 6.0 W (PEP), 1.8 W (CW)
Modulation limiting (IC-A16):
Modulation depth (IC-A16E):
70 ~ 100%
85%
Audio harmonic distortion: IC-A16
IC-A16E
Less than 10% (at 60% modulation)
Less than 10% (at 85% + 3dB modulation)
Ham and Noise ratio: More than 35 dB
Spurious emissions: IC-A16
IC-A16E
More than 46 dB*
2
*
3
Less than –36 dBm*
4
Frequency stability: IC-A16
IC-A16E
±0.4 kHz
±1 ppm
D Receiver
Receive system: Double conversion superheterodyne
Intermediate frequencies: 1st 46.35 MHz, 2nd 450 kHz
Sensitivity: IC-A16
IC-A16E
COM
NAV
WX
Less than 0 dBμ (at 6 dB S/N)
Less than 3 dBμ (at 6 dB S/N)
Less than –8 dBμ (at 12 dB SINAD)
Less than 0 dBμ
(at 12 dB SINAD with CCITT)
Squelch sensitivity (Threshold): COM/NAV
WX
Less than 0 dBμ
Less than –5 dBμ
Spurious response rejection ratio: IC-A16
IC-A16E
COM/NAV
WX
More than 60 dB
More than 30 dB
More than 70 dB
Measurements made without an antenna.
