The underlined parts have been updated from the addendum of the previous version, or from the original page.
5-2g
Eqv.= This component is equivalent to the REF No. component listed above,
and may be substituted on parts orders and repairs.
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
H/V LOCATION=See the BOARD LAYOUTS for details.
[MAIN UNIT] (for IC-A210 and IC-A210E)
REF PART
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
[MAIN UNIT] (for IC-A210 and IC-A210E)
REF PART
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
(Amended page)
July 2019
D20 1750000581 S.DIO 1SV307 (TPH3F) [#01] B 107.4/62.0
1750000581 S.DIO 1SV307 (TPH3F) [#02]
1750000581 S.DIO 1SV307 (TPH3F) [#03]
1750000581 S.DIO 1SV307 (TPH3F) [#05]
1750000581 S.DIO 1SV307 (TPH3F) [#11]
1750000581 S.DIO 1SV307 (TPH3F) [#23]
1750000581 S.DIO 1SV307 (TPH3F) [#25]
D21 1720000831 S.VAR KV1770STL-G 1-3 [#01] T 190.2/48.8
1720000831 S.VAR KV1770STL-G 1-3 [#02]
1720000831 S.VAR KV1770STL-G 1-3 [#05]
1720000831 S.VAR KV1770STL-G 1-3 [#11]
1720000831 S.VAR KV1770STL-G 1-3 [#21]
1720000831 S.VAR KV1770STL-G 1-3 [#23]
1720000831 S.VAR KV1770STL-G 1-3 [#25]
D22 1720000831 S.VAR KV1770STL-G 1-3 [#01] T 195.7/42.1
1720000831 S.VAR KV1770STL-G 1-3 [#02]
1720000831 S.VAR KV1770STL-G 1-3 [#05]
1720000831 S.VAR KV1770STL-G 1-3 [#11]
1720000831 S.VAR KV1770STL-G 1-3 [#21]
1720000831 S.VAR KV1770STL-G 1-3 [#23]
1720000831 S.VAR KV1770STL-G 1-3 [#25]
D23 1750000051 S.DIO 1SS193 (TE85RF) T 92.9/108.2
D26 1750001530 S.DIO DF10SC6-7072 T 69.3/133.9
D27 1750000581 S.DIO 1SV307 (TPH3F) T 127.5/62.6
D28 1750000581 S.DIO 1SV307 (TPH3F) [#01] T 126.7/56.7
1750000581 S.DIO 1SV307 (TPH3F) [#02]
1750000581 S.DIO 1SV307 (TPH3F) [#03]
1750000581 S.DIO 1SV307 (TPH3F) [#05]
1750000581 S.DIO 1SV307 (TPH3F) [#11]
1750000581 S.DIO 1SV307 (TPH3F) [#23]
1750000581 S.DIO 1SV307 (TPH3F) [#25]
D29 1790001241 S.DIO MA2S7280GL [#01] B 137.4/92.2
1790001241 S.DIO MA2S7280GL [#02]
1750002170 S.DIO DB2S31400L [#03]
1790001241 S.DIO MA2S7280GL [#05]
1790001241 S.DIO MA2S7280GL [#11]
1790001241 S.DIO MA2S7280GL [#21]
1750002170 S.DIO DB2S31400L [#23]
1790001241 S.DIO MA2S7280GL [#25]
D32 1750001500 S.DIO CMS15 (TE12LQ) B 130.4/130.7
D33 1750002580 S.DIO HVU187TRF-E T 153.3/86.4
D35 1750002580 S.DIO HVU187TRF-E T 155.4/77.0
D36 1750001070 S.DIO DAN235ETL B 167.5/36.6
Eqv. 1750002470 S.DIO KDS112E-RTK/P
D50 1750001500 S.DIO CMS15 (TE12LQ) B 111.6/132.1
D51 1790000991 S.ZEN MAZ8051GHL B 97.0/128.4
D52 1790001790 S.DIO RB876W TL T 134.4/55.6
D53 1750000550 S.DIO 1SS355 TE-17 T 130.7/69.2
D54 1790001521 S.ZEN MAZ8075GLL B 89.7/90.4
D55 1730002760 S.ZEN UDZSTE-17 9.1B [#03] T 156.2/111.3
1730002760 S.ZEN UDZSTE-17 9.1B [#23]
FI1 2040000501 LC BNX-002-01-Z
FI2 4580000110 S.FIL ACF321825-223-T T 103.9/121.0
FI3 2010002400 S.MON FL-306 (38.850 MHz) T 117.3/65.0
FI4 2010002410 S.MON FL-307 (38.850 MHz) [#01] T 117.3/58.2
2010002410 S.MON FL-307 (38.850 MHz) [#02]
2010002410 S.MON FL-307 (38.850 MHz) [#03]
2010002410 S.MON FL-307 (38.850 MHz) [#05]
2010002410 S.MON FL-307 (38.850 MHz) [#11]
2010002410 S.MON FL-307 (38.850 MHz) [#23]
2010002410 S.MON FL-307 (38.850 MHz) [#25]
FI5 2020002320 S.CER CFWKA450KEFA [#01] B 152.6/59.5
2020002320 S.CER CFWKA450KEFA [#02]
2020002400 S.CER CFWKA450KDFA-R0 [#03]
2020002320 S.CER CFWKA450KEFA [#05]
2020002320 S.CER CFWKA450KEFA [#11]
2020002320 S.CER CFWKA450KEFA [#21]
2020002400 S.CER CFWKA450KDFA-R0 [#23]
2020002320 S.CER CFWKA450KEFA [#25]
FI6 2020002180 S.CER CFWKA450KHFA-R0 [#01] B 143.7/59.5
2020002180 S.CER CFWKA450KHFA-R0 [#02]
2020002180 S.CER CFWKA450KHFA-R0 [#03]
2020002180 S.CER CFWKA450KHFA-R0 [#05]
2020002180 S.CER CFWKA450KHFA-R0 [#11]
2020002180 S.CER CFWKA450KHFA-R0 [#23]
2020002180 S.CER CFWKA450KHFA-R0 [#25]
X1 6070000300 S.DIS JTBM450CX24 B 134.4/59.0
X2 6050012650 S.XTA CR-860 (38.4 MHz) T 175.9/61.0
L1 6200010780 S.COI C2520C-1R0G-A B 44.7/64.6
L2 6190001591 COI #E526HNA-100312 [#01]
Eqv. 6190002480 COI E526HNA-100312 (1) [#01]
L2 6190001591 COI #E526HNA-100312 [#02]
Eqv. 6190002480 COI E526HNA-100312 (1) [#02]
L2 6190002640 COI E526HNA-100312 (2) [#03]
6190001591 COI #E526HNA-100312 [#05]
Eqv. 6190002480 COI E526HNA-100312 (1) [#05]
L2 6190001591 COI #E526HNA-100312 [#11]
Eqv. 6190002480 COI E526HNA-100312 (1) [#11]
L2 6190001591 COI #E526HNA-100312 [#21]
Eqv. 6190002480 COI E526HNA-100312 (1) [#21]
L2 6190001591 COI #E526HNA-100312 [#23]
Eqv. 6190002480 COI E526HNA-100312 (1) [#23]
L2 6190001591 COI #E526HNA-100312 [#25]
Eqv. 6190002480 COI E526HNA-100312 (1) [#25]
L3 6200010950 S.COI C2520C-1R5G-A (1.5U) [#01] B 53.1/62.5
6200010950 S.COI C2520C-1R5G-A (1.5U) [#02]
6200010440 S.COI C2520C-1R2G-A (1.2U) [#03]
6200010950 S.COI C2520C-1R5G-A (1.5U) [#05]
6200010950 S.COI C2520C-1R5G-A (1.5U) [#11]
6200010950 S.COI C2520C-1R5G-A (1.5U) [#21]
6200010950 S.COI C2520C-1R5G-A (1.5U) [#23]
6200010950 S.COI C2520C-1R5G-A (1.5U) [#25]
L4 6190001591 COI #E526HNA-100312 [#01]
Eqv. 6190002480 COI E526HNA-100312 (1) [#01]
L4 6190001591 COI #E526HNA-100312 [#02]
Eqv. 6190002480 COI E526HNA-100312 (1) [#02]
L4 6190002640 COI E526HNA-100312 (2) [#03]
6190001591 COI #E526HNA-100312 [#05]
Eqv. 6190002480 COI E526HNA-100312 (1) [#05]
L4 6190001591 COI #E526HNA-100312 [#11]
Eqv. 6190002480 COI E526HNA-100312 (1) [#11]
L4 6190001591 COI #E526HNA-100312 [#21]
Eqv. 6190002480 COI E526HNA-100312 (1) [#21]
L4 6190001591 COI #E526HNA-100312 [#23]
Eqv. 6190002480 COI E526HNA-100312 (1) [#23]
L4 6190001591 COI #E526HNA-100312 [#25]
Eqv. 6190002480 COI E526HNA-100312 (1) [#25]
L5 6200004480 S.COI MLF1608D R82K-T T 17.4/64.4
L6 6200004480 S.COI MLF1608D R82K-T T 17.4/60.2
L7 6200011450 S.COI C2520C-R39G-A B 70.9/62.8
L8 6190001591 COI #E526HNA-100312 [#01]
Eqv. 6190002480 COI E526HNA-100312 (1) [#01]
L8 6190001591 COI #E526HNA-100312 [#02]
Eqv. 6190002480 COI E526HNA-100312 (1) [#02]
L8 6190002640 COI E526HNA-100312 (2) [#03]
6190001591 COI #E526HNA-100312 [#05]
Eqv. 6190002480 COI E526HNA-100312 (1) [#05]
L8 6190001591 COI #E526HNA-100312 [#11]
Eqv. 6190002480 COI E526HNA-100312 (1) [#11]
L8 6190001591 COI #E526HNA-100312 [#21]
Eqv. 6190002480 COI E526HNA-100312 (1) [#21]
L8 6190001591 COI #E526HNA-1003122 [#23]
Eqv. 6190002480 COI E526HNA-100312 (1) [#23]
L8 6190001591 COI #E526HNA-100312 [#25]
Eqv. 6190002480 COI E526HNA-100312(1) [#25]
L9 6200010950 S.COI C2520C-1R5G-A (1.5U) [#01] B 78.9/62.5
6200010950 S.COI C2520C-1R5G-A (1.5U) [#02]
6200010440 S.COI C2520C-1R2G-A (1.2U) [#03]
6200010950 S.COI C2520C-1R5G-A (1.5U) [#05]
6200010950 S.COI C2520C-1R5G-A (1.5U) [#11]
6200010950 S.COI C2520C-1R5G-A (1.5U) [#21]
6200010950 S.COI C2520C-1R5G-A (1.5U) [#23]
6200010950 S.COI C2520C-1R5G-A (1.5U) [#25]
L10 6190001591 COI #E526HNA-100312 [#01]
Eqv. 6190002480 COI E526HNA-100312 (1) [#01]
L10 6190001591 COI #E526HNA-100312 [#02]
Eqv. 6190002480 COI E526HNA-100312 (1) [#02]
L10 6190002640 COI E526HNA-100312 (2) [#03]
6190001591 COI #E526HNA-100312 [#05]
Eqv. 6190002480 COI E526HNA-100312 (1) [#05]
L10 6190001591 COI #E526HNA-100312 [#11]
Eqv. 6190002480 COI E526HNA-100312 (1) [#11]
L10 6190001591 COI #E526HNA-100312 [#21]
Eqv. 6190002480 COI E526HNA-100312 (1) [#21]
L10 6190001591 COI #E526HNA-100312 [#23]
Eqv. 6190002480 COI E526HNA-100312 (1) [#23]
L10 6190001591 COI #E526HNA-100312 [#25]
Eqv. 6190002480 COI E526HNA-100312 (1) [#25]
L11 6200010590 S.COI C2520C-22NG-A B 109.2/55.9
L12 6200011210 S.COI C2012C-1R0J-A B 111.0/64.8
L13 6200013240 S.COI C2012C-R68J-A [#01] B 110.8/61.6
6200013240 S.COI C2012C-R68J-A [#02]
6200013240 S.COI C2012C-R68J-A [#03]
6200013240 S.COI C2012C-R68J-A [#05]
6200013240 S.COI C2012C-R68J-A [#11]
6200013240 S.COI C2012C-R68J-A [#23]
6200013240 S.COI C2012C-R68J-A [#25]
L15 6200005011 S.COI NLV25T-100J-PF T 179.4/37.7
L16 6190001690 S.COI ZBFS5105-PT-01 [#01] B 23.1/110.0
6190001690 S.COI ZBFS5105-PT-01 [#02]
6190001690 S.COI ZBFS5105-PT-01 [#05]
6190001690 S.COI ZBFS5105-PT-01 [#11]
6190001690 S.COI ZBFS5105-PT-01 [#21]
6190001690 S.COI ZBFS5105-PT-01 [#23]
6190001690 S.COI ZBFS5105-PT-01 [#25]
L17 6190001690 S.COI ZBFS5105-PT-01 [#01] B 32.1/113.4
6190001690 S.COI ZBFS5105-PT-01 [#02]
6190001690 S.COI ZBFS5105-PT-01 [#05]
6190001690 S.COI ZBFS5105-PT-01 [#11]
6190001690 S.COI ZBFS5105-PT-01 [#21]
6190001690 S.COI ZBFS5105-PT-01 [#23]
6190001690 S.COI ZBFS5105-PT-01 [#25]
L18 6190001790 S.COI 7B12HA-680M-R-0231 T 34.7/113.9
L19 6190001790 S.COI 7B12HA-680M-R-0231 T 49.7/111.0
L20 6200005011 S.COI NLV25T-100J-PF T 183.9/28.4
L21 6190001790 S.COI 7B12HA-680M-R-0231 T 64.9/111.0
L22 6200005011 S.COI NLV25T-100J-PF T 184.8/37.0
L23 6190001760 COI HK-10S080-1210H
L24 6190001780 S.COI 7E08N-330M-RA-0231 T 122.7/124.6
L25 6190001780 S.COI 7E08N-330M-RA-0231 T 147.4/126.0
L26 6190001780 S.COI 7E08N-330M-RA-0231 T 137.5/120.9
L28 6200002041 S.COI NLV25T-101J-PF T 147.8/91.8
L29 6200002041 S.COI NLV25T-101J-PF T 150.0/74.6
L31 6200007001 S.COI ELJRE 82NGFA T 177.0/29.4
