5 - 5
SOFTWARE ADJUSTMENT (continued)
ADJUSTMENT ADJUSTMENT CONDITION OPERATION
SENSITIVITY
[ ]
1 • Operating frequency: 108.025 MHz
• Connect an SSG to the antenna connector and set as:
Level : –97 dBm* (3.2 µV)
(No modulation)
• Receiving
• Push [ENT] key.
[ ]
2 • Operating frequency: 127.500 MHz
• Receiving
• Push [ENT] key.
[ ]
3 • Operating frequency: 136.975 MHz
• Receiving
• Push [ENT] key.
[ ]
4 • Operating frequency: 161.650 MHz
• Receiving
• Push [ENT] key.
[ ]
5 • Operating frequency: 163.275 MHz
• Receiving
• Push [ENT] key.
SQUELCH
[ ]
1 • Operating frequency: 108.025 MHz (IC-A24)
118.025 MHz (IC-A6)
• Connect an SSG to the antenna connector and set as:
Level : –111 dBm* (0.63 µV) for IC-A24
–114 dBm* (0.45 µV) for IC-A6
(No modulation)
• Receiving
• Push [ENT] key.
[ ]
2 • Connect an SSG to the antenna connector and set as:
Level : –114 dBm* (0.45 µV) for IC-A24
–117 dBm* (0.32 µV) for IC-A6
(No modulation)
• Receiving
• Push [ENT] key.
[ ]
3 • Connect an SSG to the antenna connector and set as:
Level : –82 dBm* (18 µV)
(No modulation)
• Receiving
• Push [ENT] key.
[ ]
4 • Connect an SSG to the antenna connector and set as:
Level : –85 dBm* (13 µV)
(No modulation)
• Receiving
• Push [ENT] key.
[ ]
5 • Operating frequency: 162.550 MHz
• Connect an SSG to the antenna connector and set as:
Level : –117 dBm* (0.32 µV)
(No modulation)
• Receiving
• Push [ENT] key.
[ ]
6 • Connect an SSG to the antenna connector and set as:
Level : –120 dBm* (0.22 µV)
(No modulation)
• Receiving
• Push [ENT] key.
[ ]
7 • Connect an SSG to the antenna connector and set as:
Level : –82 dBm* (18 µV)
(No modulation)
• Receiving
• Push [ENT] key.
[ ]
8 • Connect an SSG to the antenna connector and set as:
Level : –85 dBm* (13 µV)
(No modulation)
• Receiving
• Push [ENT] key.
*This output level of a standard signal generator (SSG) is indicated as SSG's open circuit.
