SPECIFICATIONS
D General
• Frequency coverage (MHz): TX 118.000 to 136.975
RX 108.000 to 136.975*
*: IC-A24E only, IC-A6E; 118.000 to 136.975 MHz
• Mode : A3E
• Channel spacing : 25 kHz
• Number of memory channels : 200 (20 CH × 10 BANK)
• Power supply requirement : Specified battery packs/case or
11.0 V DC at external DC jack
• Usable temp. range : –20˚C to +55˚C
• Current drain :
Tx 1.5 A typical
Rx 70 mA typical (at stand by)
300 mA typical (at AF max.)
• Antenna connector : BNC 50 Ω (nominal)
• Dimensions : 54(H) × 129.3(W) × 35.5(D) mm
(projections not incl.)
• Weight : Approx. 180 g
(Without the battery pack and antenna.)
D Transmitter
• Output power : 3.6 W (PEP) typical
1.0 W (CW) typical
• Modulation : Low level modulation
• Modulation depth : 85%
• Audio harmonic distortion : Less than 10% (at 85% ±3 dB
mod.)
• Harmonics spurious emissions
:
Less than –36 dBm (except op-
erating frequency ±1 MHz range)
• Microphone connector : 3-conductor 2.5(d) mm (
1
/
10
˝)/
more than 100 kΩ
• Frequency stability : ±5 ppm
D Receiver
• Receive system : Double conversion
superheterodyne
• Intermediate frequencies : 1st 30.05 MHz
2nd 450 kHz
•Sensitivity
VOR (AM 6dB S/N)
: –3 dBµ typical
COM (AM 12dB SINAD)
: –3 dBµ typical (with CCITT)
• Squelch sensitivity : Less than 0 dBµ (Threshold)
• Selectivity : 6 dB (More than 7.5 kHz)
60 dB (Less than 25 kHz)
• Spurious response : More than 70 dB
rejection
• Audio output power : 500 mW typical
(at 10% distortion with an 8 Ω
load, 30% mod.)
• Hum and noise : More than 40 dB at 90% mod.
• External SP connector : 3-conductor 3.5 (d) mm
(
1
/
8
˝)/8 Ω
All stated specifications are subject to change without
notice or obligation.
