Icom IC-F25 Service Manual

2
5-2 CONFIGULATION LIST FOR ADJUSTMENTS
- IC-F24S/F25S -
• Re-clone these settings every time each category is adjusted. (1−8).
CH.
FREQUENCY (MHz)
SETTING CONDITION
[US2], [EU2],
[GE2]
[US3], [GE3]
1 400.000 450.000
Set TX power to High.
2 400.000 450.000
Set TX power to Low2.
3 400.000 450.000
Set TX power to Low1.
3.TX POWER
CH.
FREQUENCY (MHz)
SETTING CONDITION
[US2], [EU2],
[GE2]
[US3], [GE3]
1 400.000 450.000
Set TX power to Low1.
2 470.000 520.000
Set TX power to Low1.
1.PLL LOCK VOLTAGE
2.REFERENCE FREQENCY
CH.
FREQUENCY (MHz)
SETTING CONDITION
[US2], [EU2],
[GE2]
[US3], [GE3]
1 435.000 485.000
Set TX power to Low1.
Set IF bandwidth to Narrow.
2 435.00 485.00
Set TX power to Low1.
Set IF bandwidth to Wide/Middle.
(Middle : [EUR] only)
4.FM DEVIATION
CH.
FREQUENCY (MHz)
SETTING CONDITION
[US2], [EU2],
[GE2]
[US3], [GE3]
1 435.000 485.000
Set TX power to Low1.
Set DTCS code to 007.
Set IF bandwidth to Narrow
.
2 435.000 485.000
Set TX power to Low1.
Set DTCS code to 007.
Set IF bandwidth to Wide/Middle
.
(Middle : [EUR] only)
5.MODULATION BALANCE
CH.
FREQUENCY (MHz)
SETTING CONDITION
[US2], [EU2],
[GE2]
[US3], [GE3]
1 435.000 485.000
Set TX power to Low1.
Set IF bandwidth to Wide.
Set CTCSS to 151.4Hz.
6.CTCSS/DTCS DEVIATION
CH.
FREQUENCY (MHz)
SETTING CONDITION
[US2], [EU2],
[GE2]
[US3], [GE3]
1 400.000 450.000 Set IF bandwidth to Wide
.
7.RX SENSITIVITY
5 - 2
- IC-F24/F25 -
CH.
FREQUENCY (MHz)
SETTING CONDITION CH.
FREQUENCY (MHz)
SETTING CONDITION
[US2], [EU2],
[GE2]
[US3], [GE3]
[US2], [EU2],
[GE2]
[US3], [GE3]
1 400.000 450.000
Set TX power to High.
7 435.000 485.000
Set TX power to Low1.
Set DTCS code to 007.
Set IF bandwidth to Wide/Middle.
(Middle : EUR only)
2 400.000 450.000
Set TX power to Low1.
8 435.000 485.000
Set TX power to Low1.
Set IF bandwidth to Narrow.
3 400.000 450.000
Set TX power to Low2.
4 435.000 485.000
Set TX power to Low1.
5 470.000 520.000
Set TX power to Low1.
9 435.000 485.000
Set TX power to Low1.
Set IF bandwidth to Wide/Middle.
(Middle : EUR only)
6 435.000 485.000
Set TX power to Low1.
Set DTCS code to 007.
Set IF bandwidth to Narrow.
10 435.000 485.000
Set TX power to Low1.
Set IF bandwidth to Wide.
Set CTCSS to151.4Hz.
11 400.000 450.000 Set IF bandwidth to Wide.
8.SQUELCH LEVEL
[US2]=USA-02, [GE2]=GEN-02, [EU2]=EUR-02, [US3]=USA-03, [GE3]=GEN-03
