6 - 1
SECTION 6 PARTS LIST
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
[MAIN UNIT]
REF ORDER
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
[MAIN UNIT]
REF ORDER
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
IC1 1110003200 S.IC TA31136FN (EL) B 51.8/19
IC2 1130008560 S.IC TC75S51F (TE85L) T 68.9/21
IC4 1140005990 S.IC MB15A02PFV1-G-BND-ER T 38.3/35.7
IC5 1110005340 S.IC NJM12902V-TE1 T 29.7/11.6
IC6 1110005320 S.IC NJM13403V-TE1 T 15.9/34.6
IC7 1110005330 S.IC NJM12904V-TE1 T 29.2/34.6
IC8 1190000350 S.IC M62363FP-650C T 40.3/15.2
IC9 1110005350 S.IC NJM2870F05-TE1 B 84.2/14.2
IC10 1130011770 S.IC CD4066BPWR T 22.9/34.6
IC12 1110001810 S.IC TA7368F (ER) T 89.3/13.2
IC13 1140012260 S.IC HD64F3687FP [US2], [GE2] T 12.5/14.3
1140012350 S.IC HD6433687A91FP [Others]
IC14 1110006260 S.IC BD5242G-TR T 6.6/5.9
IC15 1130011540 S.IC BR24L16FV-WE2 B 16/11.6
Q1 1560000840 S.FET 2SK1829 (TE85R) T 75/39.6
Q2 1580000730 S.FET 3SK293 (TE85L) B 76.8/37.9
Q3 1580000760 S.FET 3SK299-T1 U73 B 66.2/37.9
Q4 1530002600 S.TR 2SC4215-O (TE85R) B 51.4/23.1
Q5 1530000371 S.TR 2SC3356-T1B S (R25) T 74.3/33.5
Q6 1590003230 S.TR UNR9113J-(TX) T 72.5/19.1
Q7 1560001230 S.FET RD07MVS1 T 82.6/27
Q8 1560001240 S.FET RD01MUS1 T 76.1/27.5
Q9 1530003310 S.TR 2SC5107-O (TE85R) T 67/30.3
Q10 1530003310 S.TR 2SC5107-O (TE85R) T 59.4/36.3
Q11 1530003310 S.TR 2SC5107-O (TE85R) B 56.3/37
Q12 1530003310 S.TR 2SC5107-O (TE85R) T 59/31.5
Q13 1530002920 S.TR 2SC4226-T1 R25 T 54.9/30.7
Q14 1530002920 S.TR 2SC4226-T1 R25 T 54.2/37.1
Q15 1590001400 S.TR XP1214 (TX) B 56.5/32.6
Q16 1590003290 S.TR UNR9213J-(TX) B 59.1/32.6
Q17 1530002850 S.TR 2SC4116-BL (TE85R) T 55.5/44.1
Q18 1560000540 S.FET 2SK880-Y (TE85R) B 51.5/40.4
Q19 1530002850 S.TR 2SC4116-BL (TE85R) T 43.3/29.9
Q21 1510000920 S.TR 2SA1577 T106 Q T 71.9/16.4
Q22 1510000920 S.TR 2SA1577 T106 Q T 24.9/25.9
Q23 1520000460 S.TR 2SB1132 T100 R T 81/15.2
Q24 1590001190 S.TR XP6501-(TX) .AB T 76.3/15.1
Q25 1590003230 S.TR UNR9113J-(TX) T 75.7/11.7
Q26 1590003290 S.TR UNR9213J-(TX) T 49.7/18.4
Q27 1590003290 S.TR UNR9213J-(TX) T 24.8/16.7
Q28 1590003430 S.TR UNR911HJ-(TX) B 63.1/10.6
Q29 1590003270 S.TR UNR9210J-(TX) B 35.7/9.2
Q30 1510001080 S.TR 2SA2048 TLR T 91.9/8.6
Q31 1590001190 S.TR XP6501-(TX) .AB T 91.4/5.2
Q32 1590003020 S.TR XP4216-(TX) T 16.5/23.1
Q33 1590003230 S.TR UNR9113J-(TX) T 19.9/22.5
Q34 1560001360 S.FET 2SK3019 TL T 10.7/30.1
Q35 1560001360 S.FET 2SK3019 TL T 9.1/26.6
D1 1750001080 S.DIO RB886G T2R B 90.2/38.7
D2 1750000580 S.DIO 1SV307 (TPH3) B 91.5/31.1
D3 1750000710 S.VCP HVC350BTRF B 87.5/33.5
D4 1750000710 S.VCP HVC350BTRF B 87.5/34.8
D5 1790001260 S.DIO MA2S077-(TX) B 87.4/36.7
D6 1790001240 S.DIO MA2S728-(TX) B 85/39.9
D7 1750000710 S.VCP HVC350BTRF B 81.8/33.5
D8 1750000710 S.VCP HVC350BTRF B 81.8/34.8
D9 1750000710 S.VCP HVC350BTRF B 73.6/35.9
D10 1750000710 S.VCP HVC350BTRF B 72.2/35.9
D14 1790001260 S.DIO MA2S077-(TX) T 65.8/35.3
D15 1790001260 S.DIO MA2S077-(TX) T 65.8/36.7
D16 1750000710 S.VCP HVC350BTRF T 52.6/38.9
D17 1750000710 S.VCP HVC350BTRF T 49.4/28.3
D18 1720000570 S.VCP MA368 (TX) B 49.6/26.9
D21 1750000710 S.VCP HVC350BTRF T 50.5/33.7
D22 1750000710 S.VCP HVC350BTRF T 50.5/35.2
D24 1790001250 S.DIO MA2S111-(TX) T 41.5/39.2
D25 1790001250 S.DIO MA2S111-(TX) T 70.5/40.4
D26 1790001790 S.DIO RB876W TL B 35.7/7.1
D27 1750000520 S.DIO DAN222TL B 21.3/6
D28 1790001260 S.DIO MA2S077-(TX) B 8.5/11.2
D29 1750000940 S.DIO ISS400 TE61 B 23.1/4
D30 1750001080 S.DIO RB886G T2R T 88.5/36.2
D31 1790001010 S.ZEN MA8043-L (TX) B 74.5/19.9
[US3], [GE3], [US3S], [GE3S] only
FI1 2030000150 S.MLH FL-335 (46.350 MHz) B 62.8/27.7
FI2 2020001840 CER ALFYM450F=K
FI3 2040001440 S.LC NFE31PT152Z1E9L B 81.2/17.8
X1 6070000190 S.DCR CDBCB450KCAY24-R0 T 54.4/20
X2 6050011940 S.XTL CR-783 (15.3 MHz) T 36.9/28.9
X3 6050011720 S.XTL CR-764 (19.6608 MHz) B 12/5.9
L1 6200008700 S.COL 0.30-0.9-6TR 17.5N B 94.7/36.4
L2 6200008240 S.COL 0.30-0.9-5TL 14N B 94.8/31.9
L3 6200009470 S.COL 0.40-0.9-2TL B 92.9/26.3
L4 6200009470 S.COL 0.40-0.9-2TL B 89.9/20.6
L5 6200009070 S.COL LQW18AN18NG00D B 89.1/36.5
[US3], [GE3], [US3S], [GE3S]
6200010850 S.COL LQW18AN22NG00D [Others]
L7 6200007690 S.COL LQW2BHN18NJ01L B 84.3/34.5
[US3], [GE3], [US3S], [GE3S]
6200007700 S.COL LQW2BHN22NJ01L [Others]
L8 6200007690 S.COL LQW2BHN18NJ01L B 78.9/35.3
[US3], [GE3], [US3S], [GE3S]
6200007700 S.COL LQW2BHN22NJ01L [Others]
L9 6200007670 S.COL LQW2BHN10NJ01L B 75.9/35.2
[US3], [GE3], [US3S], [GE3S]
6200007680 S.COL LQW2BHN12NJ01L [Others]
L11 6200007230 S.COL LQW2BHN15NJ01L B 70.6/37.8
[US2], [EU2], [GE2], [US2S], [EU2S], [GE2S]
6200007680 S.COL LQW2BHN12NJ01L [Others]
L12 6200005720 S.COL ELJRE 33NG-F B 63.5/38.8
[US2], [EU2], [GE2], [US2S], [EU2S], [GE2S]
6200005730 S.COL ELJRE 39NG-F [Others]
L13 6200003350 S.COL ELJNC R27K-F B 66.8/33.9
L15 6200002850 S.COL NL 252018T-R82J T 94.2/32.4
L17 6200008220 S.COL 0.40-1.4-5TR 21N B 81.2/20.9
L18 6200006770 S.COL ELJRE 1N5Z-F B 81.2/20.9
L19 6200005660 S.COL ELJRE 10NG-F T 76/35.5
[US3], [GE3], [US3S], [GE3S]
6200005670 S.COL ELJRE 12NG-F [Others]
L20 6200005680 S.COL ELJRE 15NG-F T 68.8/33.1
[US3], [GE3], [US3S], [GE3S]
6200005690 S.COL ELJRE 18NG-F [Others]
L21 6200007880 S.COL ELJRF 33NJF2 (33) T 59.2/38.6
L22 6200007900 S.COL ELJRF 22NJF2 (22) T 59.5/33.3
L23 6200002850 S.COL NL 252018T-R82J T 55.2/28.1
L25 6200008490 S.COL 0.30-0.9-3TR 7.5N T 49.5/29.9
L26 6200008510 S.COL 0.30-0.9-4TR 10.5N T 49/37.9
L27 6200004950 S.COL NL 252018T-1R8J B 52.8/29
L28 6200004950 S.COL NL 252018T-1R8J B 52/36.6
L29 6200004660 S.COL MLF1608A 1R8K-T T 43.9/36.4
L30 6200007880 S.COL ELJRF 33NJF2 (33) B 85.1/38.7
L32 6200007910 S.COL ELJRF 18NJF2 (18) B 55.9/42.3
L33 6200004480 S.COL MLF1608D R82K-T T 43.4/25.9
L35 6200003540 S.COL MLF1608D R22K-T T 41.7/31.8
L38 6200005710 S.COL ELJRE 27NG-F B 65.6/40.7
L40 6200002850 S.COL NL 252018T-R82J T 53.6/34.6
L41 6200007880 S.COL ELJRF 33NJF2 (33) B 58.4/38.2
L42 6200004950 S.COL NL 252018T-1R8J B 49.4/34
L43 6200004950 S.COL NL 252018T-1R8J B 49.4/31.1
L45 6200008700 S.COL 0.30-0.9-6TR 17.5N B 94.9/39.6
R1 7030003490 S.RES ERJ3GEYJ 272 V (2.7 k
Ω
) B 91.8/39.9
R2 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) B 92.1/37.7
R3 7030004970 S.RES ERJ2GEJ 470 X (47
Ω
) T 66.7/22.7
[US2], [EU2], [GE2], [US2S], [EU2S], [GE2S]
7030005570 S.RES ERJ2GEJ 820 X (82
Ω
) [Others]
R4 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) T 75.8/20.8
R5 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) T 73.3/21.1
[US2], [EU2], [GE2], [US2S], [EU2S], [GE2S]
7030005220 S.RES ERJ2GEJ 223 X (22 k
Ω
) [Others]
R6 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) T 66.7/18.2
R7 7030005310 S.RES ERJ2GEJ 124 X (120 k
Ω
) T 68/17.7
R8 7030005100 S.RES ERJ2GEJ 154 X (150 k
Ω
) T 71.3/21.1
[US3], [GE3], [US3S], [GE3S]
7030005170 S.RES ERJ2GEJ 474 X (470 k
Ω
) [Others]
R9 7030008280 S.RES ERJ2GEJ 271 X (270
Ω
) T 71.3/22.4
R10 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) T 68.4/24
R11 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) T 85.5/36.7
R12 7030005530 S.RES ERJ2GEJ 100 X (10
Ω
) T 77.5/37.5
R13 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) T 82.3/35.7
R14 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) T 83.9/36.7
R15 7030005240 S.RES ERJ2GEJ 473 X (47 k
Ω
) B 79.1/39
R16 7030004980 S.RES ERJ2GEJ 101 X (100
Ω
) B 74.8/39.9
R17 7030004970 S.RES ERJ2GEJ 470 X (47
Ω
) B 74/33.3
R18 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) T 78.8/36.7
R19 7030005080 S.RES ERJ2GEJ 823 X (82 k
Ω
) T 78.8/38.7
R20 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) B 75.9/33.7
[US2], [EU2], [GE2], [US2S], [EU2S], [GE2S]
7030005240 S.RES ERJ2GEJ 473 X (47 k
Ω
) [Others]
[US2]=USA-02, [GE2]=GEN-02, [EU2]=EUR-02, [US3]=USA-03, [GE3]=GEN-03 S.=Surface mount
