44
10
OPTIONS
D BATTERY PACK
D CHARGERS
• BC-119N desktop charger + AD-106 charger adapter
+ BC-145 ac adapter
For rapid charging of battery packs. An AC adapter is sup-
plied with the charger depending on versions.
Charging time: approx. 3 hours when BP-232N is attached.
• BC-121N
multi-charger + AD-106 charger adapter (6 pcs.)
+ BC-157 ac adapter
For rapid charging of up to 6 battery packs (six AD-106’s
are required) simultaneously. An AC adapter should be pur-
chased separately.
Charging time: approx. 3 hours when BP-232N is attached.
• BC-160
desktop charger + BC-145 ac adapter
For rapid charging of battery packs. An AC adapter is sup-
plied with the charger depending on versions.
Charging time: approx. 3 hours when BP-232N is attached.
• BC-171
desktop charger + BC-147 ac adapter
For regular charging of battery packs. We recommend that
the BP-230N charging. An AC adapter is supplied with the
charger depending on versions.
Charging time: approx. 10 hours when BP-232N is attached.
approx. 4
hours when BP-230 is attached.
D BELT CLIPS
• MB-93 swivel belt clip
• MB-94 belt clip
Exclusive alligator-type belt clip.
• MB-96N/96F
leather belt hanger
D OPTIONAL UNITS
• UT-108 dtmf decoder unit
Provides pager and code squelch capabilities.
• UT-109 (#02)/UT-110 (#02)
scrambler units
Non-rolling type (UT-109)/Rolling type (UT-110) voice
scrambler unit provides higher communication security.
• UT-124 man down unit
Provides a measure of safety when working in a hazardous
environment, etc.
7.4 V
7.4 V
Battery case for AAA
(LR03) × 6 alkaline batteries
950 mAh (min.)
980 mAh (typ.)
1900 mAh (min.)
2000 mAh (typ.)
—*
2
13.25 hrs.
6.50 hrs.
Battery packs
BP-230N
BP-232N
BP-240
Voltage Capacity Battery life*
1
*
1
Operating periods are calculated under the following conditions;
TX : RX : standby = 5 : 5 : 90
*
2
Operating period depends on the alkaline cells used.
