5
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
S.=Surface mount
[PA-C UNIT]
REF ORDER
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
C747 4030017530 S.CER ECJ0EC1H0R5B T 34.4/12.9
C748 4030017360 S.CER ECJ0EC1H030B T 34.5/10
C750 4030006990 S.CER C1608 CH 1H 080D-T B 30.4/14
C751 4030017380 S.CER ECJ0EC1H050B B 29.6/16.4
C752 4030017600 S.CER ECJ0EC1H080C B 27.3/17.2
C753 4030017420 S.CER ECJ0EC1H470J T 26.4/18.9
C754 4030017460 S.CER ECJ0EB1E102K B 26.1/17.5
C755 4030017420 S.CER ECJ0EC1H470J B 25.2/17.5
C756 4030017460 S.CER ECJ0EB1E102K B 17.5/13.1
C757 4030017460 S.CER ECJ0EB1E102K B 17.5/14.9
C758 4030018860 S.CER ECJ0EB0J105K T 12.1/2.2
C759 4030018860 S.CER ECJ0EB0J105K B 8.2/11.7
C760 4030017730 S.CER ECJ0EB1E471K T 13.1/2.2
C761 4030017460 S.CER ECJ0EB1E102K B 15.5/18.4
C762 4030018860 S.CER ECJ0EB0J105K B 17.3/17.6
C763 4030017460 S.CER ECJ0EB1E102K B 17.9/22.7
C764 4030016790 S.CER ECJ0EB1C103K B 17.8/20.8
C765 4030006860 S.CER C1608 JB 1H 102K-T B 19.2/16.6
C766 4030016790 S.CER ECJ0EB1C103K B 21/23
C781 4030017460 S.CER ECJ0EB1E102K T 12.7/21.1
C782 4030017420 S.CER ECJ0EC1H470J T 12.7/22.1
C783 4030017360 S.CER ECJ0EC1H030B [EUR-02] B 26.5/19.7
4030017370 S.CER ECJ0EC1H3R5B [UK-02] B 26.5/19.7
J701 6510023350 S.CNR MM8430-2600RA1 B 34.1/14.3
J702 6910017680 CNR IMSA-9230B-1-04Z140-PT1
J703 6910017680 CNR IMSA-9230B-1-04Z140-PT1
F701 5210000901 S.FUS 0467003.NR (0434003) B 12.6/20.6
EP701 6910015370 S.BEA ACZ1005Y-102-T T 15/15
EP702 6910015370 S.BEA ACZ1005Y-102-T B 5.7/12.7
[CONNECT UNIT]
REF ORDER
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
L901 6200006190 S.COL BLM21PG300SN1D T 8.7/6
C901 4030017460 S.CER ECJ0EB1E102K T 5.6/6
C902 4030017420 S.CER ECJ0EC1H470J T 5.6/7
C905 4030017420 S.CER ECJ0EC1H470J B 9/6.2
C906 4030017460 S.CER ECJ0EB1E102K B 9/7.2
J901 6910015881 CNR 9230B-1-02Z141-PT1
[DSP UNIT] (UT-119S)
REF ORDER
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
IC1 1180002271 S.REG TK11250CMCL-G T 29.2/10.9
IC2 1180002590 S.REG XC6204B332MR B 12/3.7
IC3 1110006700 S.IC TB7100F (TE85L F) T 26.9/17.1
IC4 1180002590 S.REG XC6204B332MR T 22.7/10.9
IC7 1110006230 S.IC NJM2711F-TE1 T 24.6/2.3
IC8 1110005290 S.IC NJM2115V-TE1 B 21.6/12.7
IC9 1130007021 S.IC TC7S66FU (TE85L F) B 22.8/16.3
IC10 1140013280 S.IC TMS320VC5507ZHH T 7.2/11.1
IC11 1130006891 S.IC TC7S04FU (TE85R F) B 8.2/10.5
IC12 1130007281 S.IC TC7S32FU (TE85R F) B 8.2/13.4
IC13 1190002080 S.IC AD7476ARTZ-500RL7 T 17.4/3
IC16 1130012910 S.IC AK4554VTP-E2/P B 24/3
IC17 1110006230 S.IC NJM2711F-TE1 B 17.2/3.7
IC18 1140008650 S.IC HN58X2464TI B 4.2/7.2
IC20 1130012820 S.IC AT25F1024AN-10SU-2.7SL383 B 4.1/2.6
IC22 1130006891 S.IC TC7S04FU (TE85R F) T 15.1/10.8
IC23 1130013040 S.IC TC7WBD125AFK (T5L F) B 5.3/14.5
IC24 1130013040 S.IC TC7WBD125AFK (T5L F) B 14.6/14.5
IC26 1130013050 S.IC HD74LV2GT125AUSE-E B 11/14.5
Q1 1590003550 S.TR XP4313 (TX) B 19.8/17
Q2 1590003230 S.TR UNR9113J-(TX) T 23.8/8
Q3 1530003190 S.TR 2SC4617 TLQ B 33.5/4.4
D1 1750001280 S.DIO CUS02 (TE85L Q) T 24.4/14.4
D2 1790001240 S.DIO MA2S728-(TX) B 8.3/16.6
D3 1790001240 S.DIO MA2S728-(TX) B 5.1/17.6
D4 1790001240 S.DIO MA2S728-(TX) B 6.9/17.5
D5 1790001240 S.DIO MA2S728-(TX) B 4/9.9
FI1 2020002210 S.CER CFXCE450KCFA-R1 T 28.7/2.1
X1 6050012350 S.XTL CR-817 (12.288 MHz) B 14.9/9.5
[DSP UNIT] (UT-119S)
REF ORDER
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
L1 6200001620 S.COL ELJFC 1R0K-F T 32.9/9.8
L2 6200012090 S.COL CDRH2D18HP-150NC T 21.4/17.5
L3 6200007830 S.COL ELJFC 4R7K-F T 17.3/18.8
L4 6200001620 S.COL ELJFC 1R0K-F T 30/6.5
R1 7030004980 S.RES ERJ2GEJ 101 X (100) B 26.3/14.6
R2 7030005240 S.RES ERJ2GEJ 473 X (47 k
)
B 25.1/16.1
R3 7030004980 S.RES ERJ2GEJ 101 X (100) B 26.3/13.7
R4 7030004980 S.RES ERJ2GEJ 101 X (100) B 26.3/9
R5 7030004980 S.RES ERJ2GEJ 101 X (100) B 26.2/9.9
R9 7030005290 S.RES ERJ2GEJ 682 X (6.8 k
)
T 25.8/6.4
R10 7030009290 S.RES ERJ2GEJ 562 X (5.6 k
)
T 27.6/6.4
R11 7030004980 S.RES ERJ2GEJ 101 X (100) T 24.9/6.4
R12 7030005030 S.RES ERJ2GEJ 152 X (1.5 k
)
T 25.8/4.8
R13 7030004980 S.RES ERJ2GEJ 101 X (100) T 22.3/2.8
R14 7030008400 S.RES ERJ2GEJ 182 X (1.8 k
)
T 21.4/1.2
R15 7030004970 S.RES ERJ2GEJ 470 X (47) T 20.5/1.2
R16 7030005030 S.RES ERJ2GEJ 152 X (1.5 k
)
T 30/4.6
R18 7030005240 S.RES ERJ2GEJ 473 X (47 k
)
B 15.1/18.3
R19 7030005240 S.RES ERJ2GEJ 473 X (47 k
)
B 3.5/15.4
R20 7030005240 S.RES ERJ2GEJ 473 X (47 k
)
B 7.1/15.4
R22 7030004980 S.RES ERJ2GEJ 101 X (100) B 27.6/18.1
R23 7030004980 S.RES ERJ2GEJ 101 X (100) B 27.1/17.2
R24 7030004980 S.RES ERJ2GEJ 101 X (100) B 29.2/18.9
R25 7030004980 S.RES ERJ2GEJ 101 X (100) B 33.4/18.9
R26 7030004980 S.RES ERJ2GEJ 101 X (100) B 33.4/17.8
R27 7030007300 S.RES ERJ2GEJ 332 X (3.3 k
)
T 31.2/13.7
R28 7030009290 S.RES ERJ2GEJ 562 X (5.6 k
)
T 32.2/13.7
R32 7030009290 S.RES ERJ2GEJ 562 X (5.6 k
)
B 19.6/7
R33 7030005600 S.RES ERJ2GEJ 273 X (27 k
)
B 19.6/8.6
R34 7030005040 S.RES ERJ2GEJ 472 X (4.7 k
)
B 17.3/11.8
R35 7030005090 S.RES ERJ2GEJ 104 X (100 k
)
B 19.8/10.1
R36 7030009710 S.RES ERJ2GEJ 203 X (20 k
)
B 21.4/10.1
R37 7030009710 S.RES ERJ2GEJ 203 X (20 k
)
B 24.6/10.1
R38 7030009710 S.RES ERJ2GEJ 203 X (20 k
)
B 26.3/11.9
R39 7030004980 S.RES ERJ2GEJ 101 X (100) B 20.1/15.2
R41 7030004970 S.RES ERJ2GEJ 470 X (47) B 12.6/6.8
R42 7030005240 S.RES ERJ2GEJ 473 X (47 k
)
B 12.6/7.7
R43 7030004970 S.RES ERJ2GEJ 470 X (47) B 17.8/6.8
R44 7030005240 S.RES ERJ2GEJ 473 X (47 k
)
B 17.8/5.9
R45 7030005240 S.RES ERJ2GEJ 473 X (47 k
)
B 16.3/6.6
R46 7030004980 S.RES ERJ2GEJ 101 X (100) B 18.5/1.2
R47 7030007290 S.RES ERJ2GEJ 222 X (2.2 k
)
B 17.6/1.2
R48 7030005240 S.RES ERJ2GEJ 473 X (47 k
)
B 14.6/4.7
R49 7030005240 S.RES ERJ2GEJ 473 X (47 k
)
B 14.6/1.8
R50 7030010040 S.RES ERJ2GEJ-JPW B 14.6/3.8
R51 7030005120 S.RES ERJ2GEJ 102 X (1 k
)
T 29.5/19.2
R52 7030005310 S.RES ERJ2GEJ 124 X (120 k
)
T 29.5/18.2
R53 7030011060 S.RES RR0510P-273-D (27 k
)
T 21/14.3
R54 7030008260 S.RES RR0510R-393-D (39 k
)
T 22/14.3
R55 7030010040 S.RES ERJ2GEJ-JPW B 12.6/5.9
R56 7030005170 S.RES ERJ2GEJ 474 X (470 k
)
T 23/14.3
R62 7030007250 S.RES ERJ2GEJ 220 X (22) T 15.8/6.8
R63 7030005210 S.RES ERJ2GEJ 822 X (8.2 k
)
T 18.3/.8
R64 7030005210 S.RES ERJ2GEJ 822 X (8.2 k
)
T 19.6/2.8
R69 7030007290 S.RES ERJ2GEJ 222 X (2.2 k
)
B 20.5/8.6
R70 7030004980 S.RES ERJ2GEJ 101 X (100) B 26.3/7.2
R71 7030004980 S.RES ERJ2GEJ 101 X (100) B 29.3/3.9
R72 7030005240 S.RES ERJ2GEJ 473 X (47 k
)
B 28.4/2.3
R73 7030005120 S.RES ERJ2GEJ 102 X (1 k
)
B 34.2/1.6
R74 7030005120 S.RES ERJ2GEJ 102 X (1 k
)
B 31.9/3.9
R75 7030005090 S.RES ERJ2GEJ 104 X (100 k
)
B 33.8/5.9
R81 7030005040 S.RES ERJ2GEJ 472 X (4.7 k
)
T 9.9/4.3
R82 7030005040 S.RES ERJ2GEJ 472 X (4.7 k
)
T 8.3/4.3
R83 7030005040 S.RES ERJ2GEJ 472 X (4.7 k
)
T 12.3/4.3
R84 7030005050 S.RES ERJ2GEJ 103 X (10 k
)
B 2.3/9.9
R85 7030005240 S.RES ERJ2GEJ 473 X (47 k
)
T 15.5/5.6
R86 7030005240 S.RES ERJ2GEJ 473 X (47 k
)
T 21.4/4.8
R87 7030005240 S.RES ERJ2GEJ 473 X (47 k
)
T 21.8/6.1
R91 7030005050 S.RES ERJ2GEJ 103 X (10 k
)
B 10.5/8.9
R92 7030005050 S.RES ERJ2GEJ 103 X (10 k
)
B 11.4/8.9
R93 7030005240 S.RES ERJ2GEJ 473 X (47 k
)
B 8.6/1.3
R94 7030005240 S.RES ERJ2GEJ 473 X (47 k
)
B 8.6/2.9
R95 7030005240 S.RES ERJ2GEJ 473 X (47 k
)
B 8.6/3.8
R96 7030005050 S.RES ERJ2GEJ 103 X (10 k
)
B 10.5/10.8
R97 7030005050 S.RES ERJ2GEJ 103 X (10 k
)
B 11.4/10.8
C1 4030018560 S.CER C2012 JB 1A 475K-T T 32.9/12
C2 4030016930 S.CER ECJ0EB1A104K T 26.7/11.8
C3 4030016930 S.CER ECJ0EB1A104K T 29.9/8.3
C4 4030016930 S.CER ECJ0EB1A104K T 26.7/10
C5 4550007070 S.TAN TEESVP 1A 475M8R T 25.3/10.9
C6 4030018860 S.CER ECJ0EB0J105K T 26.7/8.4
C7 4030016930 S.CER ECJ0EB1A104K T 25.8/8.4
C9 4030016930 S.CER ECJ0EB1A104K T 18.4/9.9
C10 4550007030 S.TAN TEESVP 0J 106M8R T 20.1/10.9
C11 4550007070 S.TAN TEESVP 1A 475M8R B 12/1
C12 4030016930 S.CER ECJ0EB1A104K B 14.6/8
C13 4030016930 S.CER ECJ0EB1A104K B 9.8/4.1
C14 4550007030 S.TAN TEESVP 0J 106M8R B 10.1/6.3
C21 4030016930 S.CER ECJ0EB1A104K T 31.6/4.6
C22 4030018910 S.CER C1608 JB 0J 475K-T T 24.1/5
C23 4030016930 S.CER ECJ0EB1A104K T 23.6/6.1
C24 4030016930 S.CER ECJ0EB1A104K T 26.7/6.4
C25 4030016930 S.CER ECJ0EB1A104K T 26.7/4.8
C26 4030016930 S.CER ECJ0EB1A104K T 21.4/2.8
C27 4030017590 S.CER ECJ0EC1H070C T 22.3/1.2
C28 4030017730 S.CER ECJ0EB1E471K T 20.5/2.8
C31 4030016930 S.CER ECJ0EB1A104K B 18.2/15
C32 4030017460 S.CER ECJ0EB1E102K B 17.9/17.2
C33 4030016790 S.CER ECJ0EB1C103K B 17.3/13.4
C34 4030016930 S.CER ECJ0EB1A104K B 17.8/10
C35 4030017460 S.CER ECJ0EB1E102K B 23/10.1
C36 4030017450 S.CER ECJ0EB1E271K B 24.8/11
