6
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
S.=Surface mount
[DSP UNIT] (UT-119S)
REF ORDER
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
C37 4030017750 S.CER ECJ0EB1E122K B 26.3/12.8
C40 4030017420 S.CER ECJ0EC1H470J B 26.2/19.2
C41 4030017420 S.CER ECJ0EC1H470J B 25.4/18.3
C42 4030017420 S.CER ECJ0EC1H470J B 24.9/17.4
C43 4030017420 S.CER ECJ0EC1H470J T 31.2/18.2
C44 4030017420 S.CER ECJ0EC1H470J B 31.7/18.9
C45 4030017420 S.CER ECJ0EC1H470J B 26.3/15.6
C46 4030017420 S.CER ECJ0EC1H470J B 24.1/8.6
C47 4030017420 S.CER ECJ0EC1H470J B 25/8.6
C48 4030017420 S.CER ECJ0EC1H470J T 33.2/13.7
C51 4550007030 S.TAN TEESVP 0J 106M8R T 24.3/17.9
C52 4030016930 S.CER ECJ0EB1A104K T 26.2/14.2
C53 4030017770 S.CER ECJ0EB1E332K T 31.2/19.2
C54 4550006970 S.TAN TEESVA0G476M8R T 18.4/15.1
C55 4030016930 S.CER ECJ0EB1A104K T 20/14.3
C56 4550006970 S.TAN TEESVA0G476M8R T 16.2/15.1
C57 4030016790 S.CER ECJ0EB1C103K B 17.8/7.7
C61 4030016790 S.CER ECJ0EB1C103K B 13.9/17.6
C62 4030017460 S.CER ECJ0EB1E102K B 19.4/2.9
C63 4030016930 S.CER ECJ0EB1A104K B 12.6/8.6
C64 4030017430 S.CER ECJ0EC1H101J B 14.8/6.8
C65 4030016930 S.CER ECJ0EB1A104K B 14.8/5.9
C66 4030016930 S.CER ECJ0EB1A104K B 19.4/1.2
C67 4030017380 S.CER ECJ0EC1H050B B 16.7/1.2
C68 4030016930 S.CER ECJ0EB1A104K B 15.8/1.2
C71 4030016930 S.CER ECJ0EB1A104K B 33.8/7.1
C72 4030017460 S.CER ECJ0EB1E102K T 18.4/8.7
C73 4030018910 S.CER C1608 JB 0J 475K-T T 14.4/4.5
C74 4030016930 S.CER ECJ0EB1A104K T 16.5/8
C81 4030018860 S.CER ECJ0EB0J105K B 34.2/9.6
C82 4030018860 S.CER ECJ0EB0J105K B 23.2/8.6
C83 4030017460 S.CER ECJ0EB1E102K B 22.3/8.6
C84 4030018860 S.CER ECJ0EB0J105K B 20.5/7
C85 4030016930 S.CER ECJ0EB1A104K T 19.6/1.2
C86 4030018860 S.CER ECJ0EB0J105K B 26.3/8.1
C87 4030016950 S.CER ECJ0EB1A473K B 26.3/6.3
C88 4030016950 S.CER ECJ0EB1A473K B 28.4/3.9
C89 4030016930 S.CER ECJ0EB1A104K B 25/6.6
C90 4030018860 S.CER ECJ0EB0J105K B 24.1/6.6
C91 4030016930 S.CER ECJ0EB1A104K B 30.7/1.5
C92 4030018910 S.CER C1608 JB 0J 475K-T B 29.5/1.8
C93 4030018860 S.CER ECJ0EB0J105K B 30.3/3.9
C100 4030016790 S.CER ECJ0EB1C103K T 14.9/8.4
C101 4030018910 S.CER C1608 JB 0J 475K-T T 14.1/16.7
C102 4030016930 S.CER ECJ0EB1A104K B 17.3/15
C103 4030016790 S.CER ECJ0EB1C103K T 11.6/18.2
C104 4030018860 S.CER ECJ0EB0J105K T 14/8.4
C105 4030016790 S.CER ECJ0EB1C103K T 14.9/6.8
C106 4030016930 S.CER ECJ0EB1A104K T 14.4/12.7
C107 4030016790 S.CER ECJ0EB1C103K T 14/6.8
C108 4030016790 S.CER ECJ0EB1C103K B 3.2/11.2
C109 4030018860 S.CER ECJ0EB0J105K T 13.1/18.2
C110 4030016930 S.CER ECJ0EB1A104K B 3.5/13.8
C111 4030016930 S.CER ECJ0EB1A104K B 10.4/7.7
C112 4030016930 S.CER ECJ0EB1A104K B 9.8/1.2
C113 4030016930 S.CER ECJ0EB1A104K B 5.7/9.9
J1 6510025230 S.CNR AXK640345J B 30.3/11.5
EP2 6910016330 BEA MMZ1005S 601CT-S B 30.9/2.7
EP3 6910016330 BEA MMZ1005S 601CT-S T 34.2/13.7
EP4 6910016330 BEA MMZ1005S 601CT-S B 8.6/4.7
[MAIN UNIT]
REF ORDER
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
IC1 1110006480 S.IC NJM2801U1-0543-TE1 B 10.2/62.3
IC2 1110003071 S.IC uPC494GS-E1-A B 13/36.7
IC3 1140012301 S.IC uPD789112AMC-534-5A4-A B 19.1/19.6
IC4 1110002700 S.IC NJM2904M-TE1 B 35.1/13.8
Q1 1530002060 S.TR 2SC4081 T106 R B 37.3/63.9
Q2 1550000090 S.FET RSQ035P03TR B 37.3/60.9
Q3 1530002060 S.TR 2SC4081 T106 R B 35.8/19.3
Q4 1530002060 S.TR 2SC4081 T106 R B 41.6/18.3
Q5 1590000430 S.TR DTC144EUA T106 B 23.7/26.6
Q6 1530002060 S.TR 2SC4081 T106 R B 22.5/58.2
D1 1730002350 S.ZEN MA8110-M (TX) B 17.6/60.5
D2 1750000550 S.DIO 1SS355 TE-17 B 34.8/64.4
D3 1750001110 S.DIO SM240A-T B 44.4/56
D4 1160000070 S.DIO DAN202K T146 B 26.9/20.6
D5 1750000550 S.DIO 1SS355 TE-17 B 27.2/15
X1 6060000790 S.CER CSTCR4M91G B 10.3/17.7
L1 6190001640 S.COL SLF12555T-101M1R1 B 35.3/52.7
L2 6200002611 S.COL NLV25T-R47J B 20.8/28.2
R2 7030000460 S.RES MCR10EZHJ 4.7 k B 20.3/58.6
R3 7030003410 S.RES ERJ3GEYJ 561 V (560) B 37.3/65.8
R4 7030003200 S.RES ERJ3GEYJ 100 V (10) B 34.6/61.1
• BC-160
[MAIN UNIT]
REF ORDER
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
R5 7030009580 S.RES ERJ8RSJ R12V B 31.8/73
R6 7030000540 S.RES MCR10EZHJ 22 k B 30.1/26.8
R7 7030000380 S.RES MCR10EZHJ 1 k B 30.1/29.6
R8 7030003520 S.RES ERJ3GEYJ 472 V (4.7 k
)
B 39.5/18.4
R9 7030003600 S.RES ERJ3GEYJ 223 V (22 k
)
B 13.8/30.5
R10 7030000740 S.RES MCR10EZHJ 1 M B 25.8/34.9
R11 7030000540 S.RES MCR10EZHJ 22 k B 24.8/37.8
R12 7030003560 S.RES ERJ3GEYJ 103 V (10 k
)
B 10.8/30.5
R13 7030003600 S.RES ERJ3GEYJ 223 V (22 k
)
B 19.3/34.5
R14 7030003770 S.RES ERJ3GEYJ 564 V (560 k
)
B 21/34.5
R15 7030003650 S.RES ERJ3GEYJ 563 V (56 k
)
B 21/40.3
R16 7030003770 S.RES ERJ3GEYJ 564 V (560 k
)
B 19.3/40.3
R17 7030003560 S.RES ERJ3GEYJ 103 V (10 k
)
B 22.7/40.3
R18 7030003410 S.RES ERJ3GEYJ 561 V (560) B 8.6/43.5
R19 7030003620 S.RES ERJ3GEYJ 333 V (33 k
)
B 16.7/42.1
R20 7030000560 S.RES MCR10EZHJ 33 k B 28.1/40.4
R21 7030000380 S.RES MCR10EZHJ 1 k B 26.3/28.6
R22 7030000440 S.RES MCR10EZHJ 3.3 k B 24/11.4
R23 7030000460 S.RES MCR10EZHJ 4.7 k B 24/8.8
R24 7030000260 S.RES MCR10EZHJ 101 (100) B 20.3/11.4
R25 7030000260 S.RES MCR10EZHJ 101 (100) B 20.3/8.8
R26 7030000500 S.RES MCR10EZHJ 10 k B 30.5/22
R27 7030007220 S.RES ERA3YED 202V (2 k
)
B 30.2/19.6
R28 7030011200 S.RES ERA3YEB 303V (30 k
)
B 30/18.1
R29 7030011190 S.RES ERA3YEB 103V (10 k
)
B 26.9/16.6
R30 7030005871 S.RES ERA3YKD 104V (100 k
)
B 40.4/15.1
R31 7030003560 S.RES ERJ3GEYJ 103 V (10 k
)
B 29.8/15.9
R32 7030005341 S.RES ERA3YED 332V (3.3 k
)
B 43.4/11.1
R33 7030000500 S.RES MCR10EZHJ 10 k B 31.7/9.8
R34 7030000740 S.RES MCR10EZHJ 1 M B 42.1/14.4
R35 7030003440 S.RES ERJ3GEYJ 102 V (1 k
)
B 40.4/12.2
R36 7030000460 S.RES MCR10EZHJ 4.7 k B 34.7/23.8
R37 7030005501 S.RES ERA3YKD 124V (120 k
)
B 33.6/21.3
R38 7030005671 S.RES ERA3YKD 393V (39 k
)
B 30.1/25.1
R39 7030000010 S.RES MCR10EZHJ JPW B 28.1/42.2
R40 7030000010 S.RES MCR10EZHJ JPW B 27.7/8.4
R41 7030000010 S.RES MCR10EZHJ JPW B 34.6/9.2
R42 7030008240 S.RES ERJ12YJ0R00U B 38.9/7.4
R43 7030000010 S.RES MCR10EZHJ JPW B 30.1/33.3
R44 7030000010 S.RES MCR10EZHJ JPW B 28.1/33.3
R45 7030000010 S.RES MCR10EZHJ JPW B 29.1/38
R46 7030000010 S.RES MCR10EZHJ JPW B 29.1/36.1
R47 7030000010 S.RES MCR10EZHJ JPW B 43.9/18.3
R48 7030008240 S.RES ERJ12YJ0R00U B 43/28.9
R49 7030000010 S.RES MCR10EZHJ JPW B 23.5/5.7
R50 7030008240 S.RES ERJ12YJ0R00U B 34.1/38.2
R51 7030000010 S.RES MCR10EZHJ JPW B 23.9/34.9
R52 7030000010 S.RES MCR10EZHJ JPW B 24.7/32
R53 7030008240 S.RES ERJ12YJ0R00U B 38.6/33.1
R54 7030000010 S.RES MCR10EZHJ JPW B 34.4/33
R55 7030000010 S.RES MCR10EZHJ JPW B 32/60.1
R56 7030000010 S.RES MCR10EZHJ JPW B 42.1/41.5
R57 7030000010 S.RES MCR10EZHJ JPW B 37.2/41.5
R58 7030000010 S.RES MCR10EZHJ JPW B 24.9/57
R59 7030000010 S.RES MCR10EZHJ JPW B 27.6/49.3
R60 7030000010 S.RES MCR10EZHJ JPW B 16.3/58.3
R61 7030000010 S.RES MCR10EZHJ JPW B 4.9/31.7
R62 7030000010 S.RES MCR10EZHJ JPW B 39.1/41.5
R63 7030000010 S.RES MCR10EZHJ JPW B 31.4/43.6
R64 7030000010 S.RES MCR10EZHJ JPW B 40.1/38.7
R65 7030000010 S.RES MCR10EZHJ JPW B 4.9/49.5
R66 7030003560 S.RES ERJ3GEYJ 103 V (10 k
)
B 8.2/13.6
R67 7030000100 S.RES MCR10EZHJ 4R7 (4.7) B 10.2/45.1
C1 4030006900 S.CER C1608 JB 1H 103K-T B 44.5/70.7
C2 4030006900 S.CER C1608 JB 1H 103K-T B 48.2/73.5
C3 4030006860 S.CER C1608 JB 1H 102K-T B 44.5/67.8
C4 4030006900 S.CER C1608 JB 1H 103K-T B 32.9/69.7
C5 4030006900 S.CER C1608 JB 1H 103K-T B 32.9/71.1
C6 4510008540 S.ELE EEE1CA100SR B 17.5/63.8
C7 4030011600 S.CER C1608 JB 1E 104K-T B 13.4/60.8
C8 4030006900 S.CER C1608 JB 1H 103K-T B 9.2/58.7
C9 4030011600 S.CER C1608 JB 1E 104K-T B 13.4/63.8
C10 4510009150 S.ELE EEE1EA470WP B 43.6/62.8
C11 4030006900 S.CER C1608 JB 1H 103K-T B 35.8/67.9
C12 4030006900 S.CER C1608 JB 1H 103K-T B 32.4/67.9
C13 4510009150 S.ELE EEE1EA470WP B 26.5/62.8
C14 4510008660 S.ELE EEE0JA220SR B 34.3/28
C15 4510008660 S.ELE EEE0JA220SR B 40.8/23.8
C16 4030006860 S.CER C1608 JB 1H 102K-T B 12.3/30.5
C17 4030011600 S.CER C1608 JB 1E 104K-T B 19.3/37.4
C18 4030006900 S.CER C1608 JB 1H 103K-T B 21/37.4
C19 4030006900 S.CER C1608 JB 1H 103K-T B 13.1/42.2
C20 4030009980 S.CER C1608 JB 1H 152K-T B 8.6/42.1
C21 4030011600 S.CER C1608 JB 1E 104K-T B 9.5/21.9
C22 4030006900 S.CER C1608 JB 1H 103K-T B 19/25.5
C23 4030006900 S.CER C1608 JB 1H 103K-T B 26.9/23.2
C24 4030006900 S.CER C1608 JB 1H 103K-T B 26.9/18
C25 4030004760 S.CER C2012 JF 1H 104Z-T B 33.2/17.5
C26 4030006900 S.CER C1608 JB 1H 103K-T B 41.9/11.1
C27 4030006900 S.CER C1608 JB 1H 103K-T B 29.5/12.6
C28 4030006900 S.CER C1608 JB 1H 103K-T B 30.1/23.7
J1 6510024940 CNR HEC2305-016250
DS1 5040002740 LED RT3-03HRYG
