INSTALLATION AND CONNECTIONS
■ Power supply connection
Make sure the repeater’s power switch is turned OFF
when connecting a DC power cable.
R WARNING! Voltages greater than 16 V DC will
damage the repeater. Check the source voltage be-
fore connecting the power cable.
■ Mounting the repeater
D Using the supplied handles
The handles are convenient for mounting the repeater
into a 19 inch rack. The handles can be installed on
the repeater’s front panel.
q Attach the handles to both sides of the repeat-
er’s front panel with the spacers, then tighten the
screws.
P
0
P
1
P
2
P
3
P
4
Handle
Spacer
Screw
w The completed installation should look like this.
P
0
P
1
P
2
P
3
P
4
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
