PANEL DESCRIPTION
■ Function display
q TRANSMIT INDICATOR (p. 8)
Appears while transmitting.
w BUSY INDICATOR (p. 8)
Appears when receiving a signal or when the squelch
opens.
e TAG CHANNEL INDICATOR (p. 12)
Appears when a tag channel is selected.
r SCAN INDICATOR (p. 12)
Blinks while scanning.
t CALL CHANNEL INDICATOR (p. 6)
Appears when the call channel is selected.
y LOCK INDICATOR (p. 7)
Appears while the lock function is activated.
u WEATHER CHANNEL/WEATHER ALERT INDICATORS
• “WX” appears when the weather channel group is se-
lected. (p. 7)
• “ALT” appears while the weather alert function is acti-
vated; blinks when on alert tone is received.
i DUPLEX INDICATOR
Appears when a duplex channel is selected.
q w e r
y
t
u
o
!0
!1
!2!3
!5
i
!4
!6
