Page #16 background image
10
4
BASIC OPERATION
Receiving and transmitting
CAUTION: Transmitting without an antenna may damage
the transceiver.
q Push and hold [ ] to turn power ON.
w Set the volume and squelch levels.
You can enter each adjust mode with [VOL/SQL MONI].
Enter the squelch adjust mode, and push
[Z] several
times to open the squelch.
Enter the volume adjust mode, then push
[Y]/[Z] to
adjust the volume level.
Enter the squelch adjust mode again, and push
[Y]
until the noise disappears.
e Push [Y]/[Z] to select the desired channel.
When receiving a signal, “ appears and audio is emitted
from the speaker.
Further adjustment of the audio may be necessary at this point.
r Push [Hi/Lo ] to select the output power if necessary.
LOW appears when low power is selected; no indication when
high power is selected.
Choose low power for short range communications, choose
high power for longer distance communications.
• Some channels are for low power only.
t Push and hold [PTT] to transmit, then speak into the
microphone.
appears.
Channel 70 cannot be used for transmission.
y Release [PTT] to receive.
IMPORTANT: To maximize the readability of your trans-
mitted signal, pause a few sec. after pushing [PTT], hold
the microphone 2 to 4 inches (5 to 10 cm) from your
mouth and speak into the microphone at a normal voice
level.
NOTE: The transceiver has a power save function to con-
serve the battery power. The power save function acti-
vates automatically when no signal is received for 5 sec.
For U.S.A version: To prevent accidental prolonged
transmission, etc., the transceiver has a time-out timer
function. This timer cuts a transmission OFF after 5 min.
of continuous transmission.
Microphone
r Set output
power
q Power ON
t Push to
transmit
y Release to
receive
eSet channel
Enter the volume
and squelch ad-
justment mode.
w
w Adjust the
squelch and
volume level.

Other manuals for Icom IC-M36

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Icom IC-M36 and is the answer not in the manual?

Icom IC-M36 Specifications

General IconGeneral
PurposeMarine Radio Service
Operating frequency156.025 – 157.425 MHz
Antenna connector typeFA-SC58V
Number of antenna connectors1
Battery typeBP-252
Battery life (max)8 h
Battery low indicationYes
Product colorBlack
Waterproof up to1 m
International Protection (IP) codeIP57
Operating temperature (T-T)-20 - 60 °C
Number of batteries included1 pc(s)
Weight and Dimensions IconWeight and Dimensions
Depth43 mm
Width62 mm
Height139.5 mm
Weight295 g
