New2001
91
11
SPECIFICATIONS AND OPTIONS
New2001
Dimensions D
82 (3.23) 119.9 (4.72)
164.1 (6.46)
25.3
(1)
109.7 (4.32)
61.4 (2.42)
Unit: mm (inch)
180 (7.09)
Options ■
•MB-132 f l u s h m o u n t k i t
To mount the transceiver to a panel.
•HM-195
c o m m a n d m i c IV™
External microphone-type controller. Provides optional in-
tercom operation. 6 m (20 ft) microphone cable and mount-
ing base included. Black and white colors are available.
•HM-196
h a n d m i c r o p h o n e
Equipped with [Y]/[Z] (channel up/down,) [HI/LO] and [PTT]
keys, a speaker and microphone.
•OPC-1541
m i c r o p h o n e e x t e n s i o n c a b l e
6 m (20 feet) microphone extension cable for optional HM-
195
c o m m a n d m i c IV™. Up to two OPC-1541 can be con-
nected. Usable length is 18 m (60 ft) maximum.
•MA-500TR
c l a s s b a i s t r a n s p o n d e r
To transmit individual DSC calls to a selected AIS targets.
Approved Icom optional equipment is designed for optimal perfor-
mance when used with an Icom transceiver.
Icom is not responsible for the destruction or damage to an Icom
transceiver in the event the Icom transceiver is used with equipment
that is not manufactured or approved by Icom.
