6 - 2
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
S.=Surface mount
[LOGIC UNIT]
REF ORDER
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
R90 7030005080 S.RES ERJ2GEJ 823 X (82 k) T 92.6/21.3
R91 7030005240 S.RES ERJ2GEJ 473 X (47 k) T 127/28.5
R98 7030005060 S.RES ERJ2GEJ 333 X (33 k) T 69.6/16.9
R99 7030005240 S.RES ERJ2GEJ 473 X (47 k) T 124.2/34.1
R102 7030005100 S.RES ERJ2GEJ 154 X (150 k) T 68.7/16.9
R103 7030005090 S.RES ERJ2GEJ 104 X (100 k) T 70/18.5
R105 7030005090 S.RES ERJ2GEJ 104 X (100 k) T 91.8/20.1
R107 7030005160 S.RES ERJ2GEJ 105 X (1 M) T 112.1/33
R108 7030005160 S.RES ERJ2GEJ 105 X (1 M) T 113/33
R109 7030005160 S.RES ERJ2GEJ 105 X (1 M) T 113.9/33
R110 7030005210 S.RES ERJ2GEJ 822 X (8.2 k) T 110.6/32.8
R111 7030005090 S.RES ERJ2GEJ 104 X (100 k) T 109.7/32.9
R112 7030005090 S.RES ERJ2GEJ 104 X (100 k) T 108.8/32.9
R119 7030005240 S.RES ERJ2GEJ 473 X (47 k) T 75.5/18.8
R126 7030004980 S.RES ERJ2GEJ 101 X (100) T 83.7/17
R127 7030008410 S.RES ERJ2GEJ 392 X (3.9 k) T 86/19.4
R130 7030005220 S.RES ERJ2GEJ 223 X (22 k) T 77/20.7
R135 7030005170 S.RES ERJ2GEJ 474 X (470 k) T 85/17
R136 7030005090 S.RES ERJ2GEJ 104 X (100 k) T 82.1/17
R139 7030005050 S.RES ERJ2GEJ 103 X (10 k) T 83.8/16.1
R140 7030005050 S.RES ERJ2GEJ 103 X (10 k) T 84.7/14.9
R144 7030005720 S.RES ERJ2GEJ 563 X (56 k) T 87.2/15.3
R146 7030005220 S.RES ERJ2GEJ 223 X (22 k) T 88.5/17.4
R149 7030005120 S.RES ERJ2GEJ 102 X (1 k) T 86.5/52.3
R150 7030003200 S.RES ERJ3GEYJ 100 V (10) B 111.5/9.9
R151 7030003200 S.RES ERJ3GEYJ 100 V (10) B 113.9/9.1
R152 7030005050 S.RES ERJ2GEJ 103 X (10 k) T 24.1/28.9
R153 7030005040 S.RES ERJ2GEJ 472 X (4.7 k) T 24.1/30.5
R155 7030005090 S.RES ERJ2GEJ 104 X (100 k) T 28.6/35.7
R156 7030005090 S.RES ERJ2GEJ 104 X (100 k) T 28.4/34.8
R157 7030005110 S.RES ERJ2GEJ 224 X (220 k) T 45.7/31.9
R171 7030005050 S.RES ERJ2GEJ 103 X (10 k) B 68.8/24.5
R172 7030005050 S.RES ERJ2GEJ 103 X (10 k) B 58.6/33.9
R173 7030005240 S.RES ERJ2GEJ 473 X (47 k) B 65.2/27.8
R174 7030005240 S.RES ERJ2GEJ 473 X (47 k) B 85.4/35.8
R175 7030005240 S.RES ERJ2GEJ 473 X (47 k) T 91.3/32.1
R176 7030005240 S.RES ERJ2GEJ 473 X (47 k) T 92.3/32.1
R177 7030005240 S.RES ERJ2GEJ 473 X (47 k) T 93.6/32.1
R178 7030005240 S.RES ERJ2GEJ 473 X (47 k) T 90/41.8
R179 7030005240 S.RES ERJ2GEJ 473 X (47 k) T 93.6/41.8
R180 7030005160 S.RES ERJ2GEJ 105 X (1 M) B 38.2/37.4
R181 7030005240 S.RES ERJ2GEJ 473 X (47 k) T 31.3/28.1
R182 7030005240 S.RES ERJ2GEJ 473 X (47 k) T 64.8/31.6
R185 7030005120 S.RES ERJ2GEJ 102 X (1 k) T 13.7/29.4
R186 7030005240 S.RES ERJ2GEJ 473 X (47 k) T 15.3/29.4
R187 7030005240 S.RES ERJ2GEJ 473 X (47 k) T 63.7/35.3
R188 7030005240 S.RES ERJ2GEJ 473 X (47 k) T 64.9/34.4
R189 7030005240 S.RES ERJ2GEJ 473 X (47 k) T 64.9/35.3
R191 7030005240 S.RES ERJ2GEJ 473 X (47 k) B 66.6/49.7
R192 7030005240 S.RES ERJ2GEJ 473 X (47 k) B 78/44.7
R195 7030010040 S.RES ERJ2GEJ-JPW B 76.8/43.9
R197 7030008010 S.RES ERJ2GEJ 123 X (12 k) B 68.5/20.8
R198 7030007320 S.RES ERJ2GEJ 225 X (2.2 M) B 67.3/22
R199 7030005090 S.RES ERJ2GEJ 104 X (100 k) B 71/20.9
R201 7510001661 S.TMR NTCG16 4LH 473JT B 93.4/8
R202 7030005090 S.RES ERJ2GEJ 104 X (100 k) B 94.5/8.8
R203 7030005120 S.RES ERJ2GEJ 102 X (1 k) T 45.2/39.2
R204 7030005120 S.RES ERJ2GEJ 102 X (1 k) T 45.6/42.4
R206 7030005120 S.RES ERJ2GEJ 102 X (1 k) T 51.8/24.2
R207 7030005050 S.RES ERJ2GEJ 103 X (10 k) B 26.4/23.4
R208 7030006610 S.RES ERJ2GEJ 394 X (390 k) B 24.8/23.4
R209 7030005160 S.RES ERJ2GEJ 105 X (1 M) B 96/39.4
R210 7030005160 S.RES ERJ2GEJ 105 X (1 M) T 79.8/7
R211 7030000020 S.RES MCR10EZHJ 1 (010) T 72.7/51.4
R212 7030005090 S.RES ERJ2GEJ 104 X (100 k) T 41.9/40.8
R213 7030005240 S.RES ERJ2GEJ 473 X (47 k) B 65/39.5
R215 7030005050 S.RES ERJ2GEJ 103 X (10 k) T 43.7/28.3
R216 7030005050 S.RES ERJ2GEJ 103 X (10 k) T 44.9/29.2
R217 7030005050 S.RES ERJ2GEJ 103 X (10 k) T 47.7/28.7
R218 7030005600 S.RES ERJ2GEJ 273 X (27 k) T 42.1/27.7
R219 7030005600 S.RES ERJ2GEJ 273 X (27 k) T 45.3/27.9
R220 7030005600 S.RES ERJ2GEJ 273 X (27 k) T 46.5/28.3
R221 7030005010 S.RES ERJ2GEJ 681 X (680) T 46/18
R222 7030005090 S.RES ERJ2GEJ 104 X (100 k) B 81.2/23.3
R224 7030005050 S.RES ERJ2GEJ 103 X (10 k) T 52.9/52.5
R225 7030005050 S.RES ERJ2GEJ 103 X (10 k) T 48.8/54.8
R226 7030005240 S.RES ERJ2GEJ 473 X (47 k) T 67.8/16.9
R227 7030005240 S.RES ERJ2GEJ 473 X (47 k) B 71/21.8
R229 7030005120 S.RES ERJ2GEJ 102 X (1 k) B 80.1/22.3
R230 7030005120 S.RES ERJ2GEJ 102 X (1 k) T 91.7/18.9
R231 7030005120 S.RES ERJ2GEJ 102 X (1 k) T 76.4/27.6
R234 7030005120 S.RES ERJ2GEJ 102 X (1 k) T 44.5/31.6
R235 7030004980 S.RES ERJ2GEJ 101 X (100) B 33.4/21.8
R240 7030003560 S.RES ERJ3GEYJ 103 V (10 k) T 36.6/43.3
R241 7030005220 S.RES ERJ2GEJ 223 X (22 k) B 11.4/54.6
R242 7030005220 S.RES ERJ2GEJ 223 X (22 k) T 39.5/24.4
R243 7030004980 S.RES ERJ2GEJ 101 X (100) T 40.7/25.8
R244 7030010040 S.RES ERJ2GEJ-JPW T 77/19.1
R245 7030005160 S.RES ERJ2GEJ 105 X (1 M) B 26.8/22.2
R246 7030005290 S.RES ERJ2GEJ 682 X (6.8 k) T 84.3/33.6
R247 7030005290 S.RES ERJ2GEJ 682 X (6.8 k) T 83.2/34.6
[LOGIC UNIT]
REF ORDER
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
R248 7030005290 S.RES ERJ2GEJ 682 X (6.8 k) T 82.7/33.6
R249 7030005290 S.RES ERJ2GEJ 682 X (6.8 k) T 83.3/32
R250 7030005090 S.RES ERJ2GEJ 104 X (100 k) T 61.3/49.9
R251 7030005120 S.RES ERJ2GEJ 102 X (1 k) T 63/49.9
R252 7030005120 S.RES ERJ2GEJ 102 X (1 k) B 68.3/50.6
R260 7030005090 S.RES ERJ2GEJ 104 X (100 k) B 56.2/35.4
R261 7030005090 S.RES ERJ2GEJ 104 X (100 k) T 40/45.2
R263 7030010040 S.RES ERJ2GEJ-JPW T 25/41.3
R265 7030010040 S.RES ERJ2GEJ-JPW T 28.4/41.3
R266 7030010040 S.RES ERJ2GEJ-JPW T 28.4/40.4
R269 7030005220 S.RES ERJ2GEJ 223 X (22 k) T 30.5/39.1
R270 7030005220 S.RES ERJ2GEJ 223 X (22 k) T 31.1/40.8
R2003* 7030007850 S.RES ERJ8ENF 1001V (1 k) T 134/28.1
R2013* 7030005040 S.RES ERJ2GEJ 472 X (4.7 k) T 74.6/48.6
R2050* 7030005600 S.RES ERJ2GEJ 273 X (27 k) T 49.4/33.1
R2058* 7030004980 S.RES ERJ2GEJ 101 X (100) T 48.5/33.1
R2060* 7030005040 S.RES ERJ2GEJ 472 X (4.7 k) T 51.6/27.7
R2068* 7030008300 S.RES ERJ2GEJ 184 X (180 k) T 28.7/18.4
R2072* 7030005310 S.RES ERJ2GEJ 124 X (120 k) T 23.8/23.6
R2073* 7030009150 S.RES ERJ2GEJ 824 X (820 k) T 29.6/18.4
R2074* 7030008010 S.RES ERJ2GEJ 123 X (12 k) T 22.5/20.5
R2075* 7030005700 S.RES ERJ2GEJ 274 X (270 k) T 31.4/18.4
R2079* 7030005170 S.RES ERJ2GEJ 474 X (470 k) T 24.6/20.5
R2080* 7030005080 S.RES ERJ2GEJ 823 X (82 k) T 23.7/20.5
R2082* 7030007350 S.RES ERJ2GEJ 393 X (39 k) T 35/22.6
R2083* 7030005100 S.RES ERJ2GEJ 154 X (150 k) T 35.4/21.7
R2086* 7030007350 S.RES ERJ2GEJ 393 X (39 k) T 36.9/20.4
R2088* 7030004980 S.RES ERJ2GEJ 101 X (100) T 46.9/18
R2089* 7030007290 S.RES ERJ2GEJ 222 X (2.2 k) T 47.8/18
R2090* 7030005080 S.RES ERJ2GEJ 823 X (82 k) T 22.5/19.3
R2093* 7030005050 S.RES ERJ2GEJ 103 X (10 k) T 115.7/35.1
R2094* 7030005050 S.RES ERJ2GEJ 103 X (10 k) T 115.7/34.2
R2096* 7030010040 S.RES ERJ2GEJ-JPW T 115.7/33.3
R2098* 7030005060 S.RES ERJ2GEJ 333 X (33 k) T 48.7/12.9
R2102* 7030005100 S.RES ERJ2GEJ 154 X (150 k) T 47.8/12.9
R2103* 7030005090 S.RES ERJ2GEJ 104 X (100 k) T 46.6/13.9
R2105* 7030005090 S.RES ERJ2GEJ 104 X (100 k) T 25.6/22.9
R2115* 7030007300 S.RES ERJ2GEJ 332 X (3.3 k) T 66/20.3
R2116* 7030007300 S.RES ERJ2GEJ 332 X (3.3 k) T 127/17.8
R2117* 7030005050 S.RES ERJ2GEJ 103 X (10 k) T 71/20.5
R2119* 7030005240 S.RES ERJ2GEJ 473 X (47 k) T 38.9/16.7
R2120* 7030004980 S.RES ERJ2GEJ 101 X (100) T 53/38.2
R2121* 7030005050 S.RES ERJ2GEJ 103 X (10 k) T 122.7/17
R2122* 7030004980 S.RES ERJ2GEJ 101 X (100) T 119.8/20.6
R2125* 7030005000 S.RES ERJ2GEJ 471 X (470) T 53.9/38.2
R2126* 7030004980 S.RES ERJ2GEJ 101 X (100) T 39.8/13.5
R2127* 7030008410 S.RES ERJ2GEJ 392 X (3.9 k) T 29/14.6
R2128* 7030007340 S.RES ERJ2GEJ 153 X (15 k) T 118.8/20.6
R2130* 7030005220 S.RES ERJ2GEJ 223 X (22 k) T 38.9/13.5
R2131* 7030005040 S.RES ERJ2GEJ 472 X (4.7 k) T 55/38
R2132* 7030007320 S.RES ERJ2GEJ 225 X (2.2 M) T 121.1/18.4
R2135* 7030005170 S.RES ERJ2GEJ 474 X (470 k) T 32.6/17.9
R2136* 7030005090 S.RES ERJ2GEJ 104 X (100 k) T 33.5/17.9
R2139* 7030005050 S.RES ERJ2GEJ 103 X (10 k) T 39.3/18.7
R2140* 7030005050 S.RES ERJ2GEJ 103 X (10 k) T 34.4/17.9
R2141* 7030005080 S.RES ERJ2GEJ 823 X (82 k) T 117.6/19.3
R2143* 7030005080 S.RES ERJ2GEJ 823 X (82 k) T 117.2/18.1
R2144* 7030005720 S.RES ERJ2GEJ 563 X (56 k) T 27.8/14.3
R2146* 7030005220 S.RES ERJ2GEJ 223 X (22 k) T 26.9/16.7
R2147* 7030003200 S.RES ERJ3GEYJ 100 V (10) T 43.1/9.5
R2148* 7030003200 S.RES ERJ3GEYJ 100 V (10) B 45/9
R2149* 7030005120 S.RES ERJ2GEJ 102 X (1 k) T 74.9/52.9
R2150* 7030005120 S.RES ERJ2GEJ 102 X (1 k) T 55.2/29.6
R2151* 7030005090 S.RES ERJ2GEJ 104 X (100 k) B 84.1/26.5
R2152* 7030006610 S.RES ERJ2GEJ 394 X (390 k) T 39.8/15.1
R2157* 7030005110 S.RES ERJ2GEJ 224 X (220 k) T 50.3/31.5
R2159* 7030005090 S.RES ERJ2GEJ 104 X (100 k) T 55.1/36.4
R2160* 7030005120 S.RES ERJ2GEJ 102 X (1 k) T 54.8/33.7
R2206* 7030005120 S.RES ERJ2GEJ 102 X (1 k) T 51.2/26.5
R2214* 7030005160 S.RES ERJ2GEJ 105 X (1 M) T 81.4/28.4
R2226* 7030005240 S.RES ERJ2GEJ 473 X (47 k) B 43/15.4
R2229* 7030005120 S.RES ERJ2GEJ 102 X (1 k) T 84.2/26.8
R2230* 7030005120 S.RES ERJ2GEJ 102 X (1 k) B 86.4/27.7
R2234* 7030005120 S.RES ERJ2GEJ 102 X (1 k) T 49.9/29.8
R2237* 7030005090 S.RES ERJ2GEJ 104 X (100 k) T 24.4/11.9
R2238* 7030006610 S.RES ERJ2GEJ 394 X (390 k) T 25/13.1
R2239* 7030005090 S.RES ERJ2GEJ 104 X (100 k) T 39.8/16.7
R2244* 7030010040 S.RES ERJ2GEJ-JPW T 38.9/15.1
R2246* 7030005090 S.RES ERJ2GEJ 104 X (100 k) T 116/24.2
R2247* 7030010040 S.RES ERJ2GEJ-JPW T 115.7/28.3
R2248* 7030005240 S.RES ERJ2GEJ 473 X (47 k) B 88.6/10.4
R2249* 7030005060 S.RES ERJ2GEJ 333 X (33 k) T 63.2/29.2
R2250* 7030010040 S.RES ERJ2GEJ-JPW B 87.5/11.5
C1 4030006900 S.CER C1608 JB 1H 103K-T T 47.3/42.5
C2 4510008130 S.ELE 16 CE 220 BS B 43.9/40
C3 4510009150 S.ELE EEE1EA470WP B 13.5/11.7
C5 4510009150 S.ELE EEE1EA470WP B 122.2/43
C6 4510009150 S.ELE EEE1EA470WP B 106.9/41.1
C7 4030006860 S.CER C1608 JB 1H 102K-T T 105.2/29
*IC-PCR2500 only
