6 - 19
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
[MAIN-B UNIT] (IC-PCR2500 only)
REF ORDER
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
C725 4030017440 S.CER ECJ0EC1H221J B 34.5/9.7
C726 4030017440 S.CER ECJ0EC1H221J B 34.5/8.7
C727 4030017440 S.CER ECJ0EC1H221J B 35.1/7
C728 4030017460 S.CER ECJ0EB1E102K B 35.5/16.2
C729 4030017460 S.CER ECJ0EB1E102K B 35.4/13.2
J1 6510018450 CNR TMP-S01X-B1
J2 6510020531 S.CNR 52808-1871 T 124.9/14.2
J3 6510020531 S.CNR 52808-1871 T 124.9/36.2
J5 6510018450 CNR TMP-S01X-B1
EP1 6910012350 S.BEA MMZ1608Y 102BT B 65.3/16.9
EP2 6910012350 S.BEA MMZ1608Y 102BT B 63.5/16.1
EP3 6910012350 S.BEA MMZ1608Y 102BT T 73.3/29
EP4 6910012350 S.BEA MMZ1608Y 102BT T 66.9/28.7
EP5 6910014690 S.BEA MPZ1608S221A-T T 118.9/26.3
EP6 6910014690 S.BEA MPZ1608S221A-T T 125/2
EP7 6910014690 S.BEA MPZ1608S221A-T T 119.8/22.7
EP8 6910014690 S.BEA MPZ1608S221A-T T 118.1/9.7
S.=Surface mount
[MAIN UNIT]
REF ORDER
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
IC1 1180002590 S.REG XC6204B332MR B 2.1/19.5
IC2 1180002860 S.REG XC9215A15CMR B 3/30.4
IC3 1180002590 S.REG XC6204B332MR T 23.7/7.5
IC4 1110003800 S.IC NJM2904V-TE1 T 14.5/11.8
IC5 1110006230 S.IC NJM2711F-TE1 B 14.6/16.4
IC7 1140011981 S.IC TMS320VC5416ZGU120 B 11.8/30.4
IC8 1190002080 S.IC AD7476ARTZ-500RL7 T 14.7/18.4
IC9 1130011610 S.IC AK4550VT-E2 T 23.5/19.3
IC10 1110006230 S.IC NJM2711F-TE1 T 24.2/29.8
IC12 1140011881 S.IC HD64F2239TE16V T 11.8/30.4
IC14 1110005731 S.IC S-80928CNMC-G8Y-G B 19.6/38.1
IC15 1130011600 S.IC TC7MET541AFK (EC) T 7/16.4
IC17 1130010390 S.IC HN58X2416TI B 8.9/38.5
Q1 1530002060 S.TR 2SC4081 T106 R B 23.4/21.9
FI1 2020002320 S.CER CFWKA450KEFA B 20.7/12.1
X1 6050012080 S.XTL CR-798 (12.288 MHz) T 23.4/36.4
L1 6200003590 S.COL EXCCL3225U1 T 23.5/2.5
L2 6200003960 S.COL MLF1608A 1R0K-T B 3.6/23.6
L3 6200003960 S.COL MLF1608A 1R0K-T T 24.6/12.1
L4 6200003960 S.COL MLF1608A 1R0K-T T 1/24.3
L5 6200003960 S.COL MLF1608A 1R0K-T B 3.6/24.8
L6 6200003960 S.COL MLF1608A 1R0K-T B 3.7/37.2
L7 6200011440 S.COL NLFV25T-330K-PF B 3.1/33.3
L8 6200003960 S.COL MLF1608A 1R0K-T B 21.1/5.4
R1 7030003860 S.RES ERJ3GE JPW V B 3.7/26
R2 7030005030 S.RES ERJ2GEJ 152 X (1.5 k) B 16.3/6.4
R3 7030004980 S.RES ERJ2GEJ 101 X (100) B 8.2/8
R4 7030004980 S.RES ERJ2GEJ 101 X (100) T 19.6/8.4
R5 7030004980 S.RES ERJ2GEJ 101 X (100) B 14/12.6
R6 7030004980 S.RES ERJ2GEJ 101 X (100) B 11.5/16.8
R7 7030005030 S.RES ERJ2GEJ 152 X (1.5 k) B 15.5/13.9
R9 7030005040 S.RES ERJ2GEJ 472 X (4.7 k) B 20.7/21.9
R10 7030009710 S.RES ERJ2GEJ 203 X (20 k) T 17.5/13.9
R12 7030005120 S.RES ERJ2GEJ 102 X (1 k) T 4.3/9.8
R15 7030005120 S.RES ERJ2GEJ 102 X (1 k) T 11.1/8.6
R16 7030009710 S.RES ERJ2GEJ 203 X (20 k) T 18.8/11.3
R17 7030008400 S.RES ERJ2GEJ 182 X (1.8 k) B 21.6/21.2
R18 7030009290 S.RES ERJ2GEJ 562 X (5.6 k) B 21.8/19.4
R19 7030007340 S.RES ERJ2GEJ 153 X (15 k) B 13.7/13.9
R20 7030005050 S.RES ERJ2GEJ 103 X (10 k) T 15.6/14.3
R21 7030005040 S.RES ERJ2GEJ 472 X (4.7 k) T 11.2/13.9
R22 7030005120 S.RES ERJ2GEJ 102 X (1 k) B 4.3/6.6
R23 7030005120 S.RES ERJ2GEJ 102 X (1 k) B 5.5/8
R24 7030005120 S.RES ERJ2GEJ 102 X (1 k) B 1.9/10.3
R25 7030005120 S.RES ERJ2GEJ 102 X (1 k) B 7.3/8
R26 7030005120 S.RES ERJ2GEJ 102 X (1 k) T 15.3/9.3
R27 7030005120 S.RES ERJ2GEJ 102 X (1 k) T 2.7/7.6
R28 7030005120 S.RES ERJ2GEJ 102 X (1 k) B 6.4/8
R29 7030005120 S.RES ERJ2GEJ 102 X (1 k) T 4.6/6.2
[MAIN UNIT]
REF ORDER
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
R30 7030005120 S.RES ERJ2GEJ 102 X (1 k) T 3.9/4.3
R31 7030005120 S.RES ERJ2GEJ 102 X (1 k) T 3.6/2.8
R32 7030005120 S.RES ERJ2GEJ 102 X (1 k) B 14.2/5.1
R33 7030009710 S.RES ERJ2GEJ 203 X (20 k) T 19.6/9.6
R34 7030009710 S.RES ERJ2GEJ 203 X (20 k) T 18.9/13.5
R35 7030005040 S.RES ERJ2GEJ 472 X (4.7 k) B 19.6/19.5
R36 7030004970 S.RES ERJ2GEJ 470 X (47) B 18.4/19.2
R37 7030005120 S.RES ERJ2GEJ 102 X (1 k) T 18/17.7
R38 7030007300 S.RES ERJ2GEJ 332 X (3.3 k) T 17.7/16
R39 7030009290 S.RES ERJ2GEJ 562 X (5.6 k) T 17.7/15.1
R41 7030005240 S.RES ERJ2GEJ 473 X (47 k) B 16.5/37.9
R42 7030007250 S.RES ERJ2GEJ 220 X (22) T 12.1/16.1
R43 7030005210 S.RES ERJ2GEJ 822 X (8.2 k) B 17.1/18.7
R45 7030005210 S.RES ERJ2GEJ 822 X (8.2 k) T 11.6/17.4
R46 7030005040 S.RES ERJ2GEJ 472 X (4.7 k) B 14.7/22.5
R47 7030004980 S.RES ERJ2GEJ 101 X (100) T 18.3/20
R48 7030005050 S.RES ERJ2GEJ 103 X (10 k) T 23.8/14.9
R49 7030010040 S.RES ERJ2GEJ-JPW T 25/14.6
R50 7030005040 S.RES ERJ2GEJ 472 X (4.7 k) T 20.9/32.2
R52 7030005050 S.RES ERJ2GEJ 103 X (10 k) B 20.6/27.2
R53 7030005040 S.RES ERJ2GEJ 472 X (4.7 k) B 19.8/30.6
R54 7030005040 S.RES ERJ2GEJ 472 X (4.7 k) T 6.1/20.7
R55 7030005040 S.RES ERJ2GEJ 472 X (4.7 k) T 2.7/34.4
R56 7030005040 S.RES ERJ2GEJ 472 X (4.7 k) B 19.4/32.1
R57 7030005120 S.RES ERJ2GEJ 102 X (1 k) B 23.2/19.2
R58 7030005120 S.RES ERJ2GEJ 102 X (1 k) B 24.4/20
R59 7030004970 S.RES ERJ2GEJ 470 X (47) T 25.7/37.3
R61 7030005240 S.RES ERJ2GEJ 473 X (47 k) B 25.1/21.9
R62 7030005240 S.RES ERJ2GEJ 473 X (47 k) T 25.7/32.7
R63 7030005240 S.RES ERJ2GEJ 473 X (47 k) T 25.7/34.3
R64 7030005240 S.RES ERJ2GEJ 473 X (47 k) B 5.3/11.6
R65 7030004970 S.RES ERJ2GEJ 470 X (47) T 25.7/27.2
R66 7030005240 S.RES ERJ2GEJ 473 X (47 k) B 7.3/19.2
R67 7030007290 S.RES ERJ2GEJ 222 X (2.2 k) T 22/28.4
R68 7030005090 S.RES ERJ2GEJ 104 X (100 k) T 22/25.9
R70 7030008290 S.RES ERJ2GEJ 183 X (18 k) T 9.1/10.2
R71 7030005600 S.RES ERJ2GEJ 273 X (27 k) T 8.2/10.2
R72 7030008290 S.RES ERJ2GEJ 183 X (18 k) T 7.3/10.2
R73 7030005600 S.RES ERJ2GEJ 273 X (27 k) T 6.4/9.2
R74 7030005600 S.RES ERJ2GEJ 273 X (27 k) T 5.5/9.2
R75 7030005050 S.RES ERJ2GEJ 103 X (10 k) T 9.3/12.4
R76 7030007340 S.RES ERJ2GEJ 153 X (15 k) T 8.4/12.4
R77 7030005050 S.RES ERJ2GEJ 103 X (10 k) T 7.5/12.9
R78 7030007340 S.RES ERJ2GEJ 153 X (15 k) T 6.6/12.7
R79 7030007340 S.RES ERJ2GEJ 153 X (15 k) T 5.7/12
R80 7030005240 S.RES ERJ2GEJ 473 X (47 k) B 20.1/35.5
R82 7030005240 S.RES ERJ2GEJ 473 X (47 k) T 3.5/17.2
R83 7030005050 S.RES ERJ2GEJ 103 X (10 k) B 2.1/38.6
R85 7030005050 S.RES ERJ2GEJ 103 X (10 k) B 4.3/38.8
R87 7030005240 S.RES ERJ2GEJ 473 X (47 k) T 10.7/18.5
R89 7030010040 S.RES ERJ2GEJ-JPW T 3.3/37.4
R90 7030008370 S.RES ERJ2GEJ 561 X (560) T 22/30
R91 7030005240 S.RES ERJ2GEJ 473 X (47 k) T 23.3/25.1
R92 7030005240 S.RES ERJ2GEJ 473 X (47 k) T 24.5/25.1
R93 7030007260 S.RES ERJ2GEJ 330 X (33) T 23.1/23.9
R94 7030005240 S.RES ERJ2GEJ 473 X (47 k) T 7.8/19.8
R95 7030005240 S.RES ERJ2GEJ 473 X (47 k) T 17.1/19.6
R96 7030005120 S.RES ERJ2GEJ 102 X (1 k) T 1.6/11.8
R97 7030005120 S.RES ERJ2GEJ 102 X (1 k) T 1.9/18.6
R100 7030010040 S.RES ERJ2GEJ-JPW T 2.5/23.3
C1 4550007070 S.TAN TEESVP 1A 475M8R B 1.2/15.3
C2 4550007070 S.TAN TEESVP 1A 475M8R B 2/27.6
C3 4550007070 S.TAN TEESVP 1A 475M8R T 23/4.9
C4 4030017420 S.CER ECJ0EC1H470J B 22.7/1.7
C5 4030016930 S.CER ECJ0EB1A104K B 1.3/17.3
C6 4030016930 S.CER ECJ0EB1A104K B 4.4/27.2
C7 4030016930 S.CER ECJ0EB1A104K T 21.5/7.7
C8 4030016930 S.CER ECJ0EB1A104K B 23.7/5.6
C9 4030017420 S.CER ECJ0EC1H470J B 9.1/8
C10 4550006250 S.TAN TEESVA 1A 106M8R B 23.5/3.3
C11 4030017460 S.CER ECJ0EB1E102K B 5.9/23.4
C12 4030017460 S.CER ECJ0EB1E102K B 4.9/35.2
C13 4030017460 S.CER ECJ0EB1E102K T 24.5/10
C14 4550007030 S.TAN TEESVP 0J 106M8R B 4.9/21.3
C15 4550007030 S.TAN TEESVP 0J 106M8R B 2.9/35.6
C16 4550007030 S.TAN TEESVP 0J 106M8R T 22.4/10.8
C17 4550006250 S.TAN TEESVA 1A 106M8R B 14.8/9.5
C18 4030016930 S.CER ECJ0EB1A104K B 16.4/12.7
C19 4030016930 S.CER ECJ0EB1A104K B 16.4/11.5
C20 4030017420 S.CER ECJ0EC1H470J T 17.5/9.7
C21 4550006250 S.TAN TEESVA 1A 106M8R B 11.8/13
C22 4030016930 S.CER ECJ0EB1A104K B 12.4/16.8
C23 4030017680 S.CER ECJ0EC1H820J B 13.2/9
C24 4030017730 S.CER ECJ0EB1E471K T 18.4/9.7
C26 4030016930 S.CER ECJ0EB1A104K T 14/14.3
C27 4030017590 S.CER ECJ0EC1H070C B 14.6/13.9
C28 4030016930 S.CER ECJ0EB1A104K B 20.9/19.4
C30 4030017450 S.CER ECJ0EB1E271K T 19.3/14.7
C31 4030017420 S.CER ECJ0EC1H470J T 4.9/13.2
• UT-122
(Optional product; DIGITAL UNIT for [PCR2500: USA-3]
