Icom IC-R2500 Service Manual

6 - 20
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
S.=Surface mount
[MAIN UNIT]
REF ORDER
DESCRIPTION M.
H/V
NO. NO.
LOCATION
C32 4030016930 S.CER ECJ0EB1A104K B 19.6/18.6
C33 4030016790 S.CER ECJ0EB1C103K T 12.4/14.6
C35 4030017420 S.CER ECJ0EC1H470J B 3.1/7.2
C36 4030017420 S.CER ECJ0EC1H470J B 4.3/7.5
C38 4030017420 S.CER ECJ0EC1H470J B 3/11.3
C39 4030017760 S.CER ECJ0EB1H222K B 19.6/20.4
C40 4030017420 S.CER ECJ0EC1H470J B 7.8/9.9
C41 4030017420 S.CER ECJ0EC1H470J T 12.9/9.3
C42 4030017420 S.CER ECJ0EC1H470J T 3.2/8.8
C43 4030017460 S.CER ECJ0EB1E102K B 16.5/39.7
C44 4030017420 S.CER ECJ0EC1H470J T 7.6/8.7
C45 4030017420 S.CER ECJ0EC1H470J B 3.9/8.7
C46 4030017420 S.CER ECJ0EC1H470J T 3.4/6.4
C47 4030017460 S.CER ECJ0EB1E102K B 18.6/26.9
C48 4030017460 S.CER ECJ0EB1E102K B 18.7/34.9
C49 4030017420 S.CER ECJ0EC1H470J T 3.4/5.5
C50 4030017420 S.CER ECJ0EC1H470J T 2.4/3.7
C51 4030017420 S.CER ECJ0EC1H470J B 15.1/5.1
C52 4030016930 S.CER ECJ0EB1A104K B 17.1/19.6
C53 4030017460 S.CER ECJ0EB1E102K B 18.8/33.7
C55 4550007030 S.TAN TEESVP 0J 106M8R T 14.8/15.7
C56 4030017460 S.CER ECJ0EB1E102K T 18.4/20.9
C57 4030017460 S.CER ECJ0EB1E102K B 12.3/21.4
C58 4030016930 S.CER ECJ0EB1A104K T 12.5/17.4
C59 4030017460 S.CER ECJ0EB1E102K T 22/33.1
C60 4030017760 S.CER ECJ0EB1H222K T 22.1/14.9
C62 4030017460 S.CER ECJ0EB1E102K B 12.8/20.5
C63 4030016930 S.CER ECJ0EB1A104K T 19.9/20
C64 4030017460 S.CER ECJ0EB1E102K T 23/14
C65 4030016930 S.CER ECJ0EB1A104K T 18.9/17.6
C66 4550007030 S.TAN TEESVP 0J 106M8R T 22.4/12.6
C67 4030017490 S.CER C1608 JB 1A 105K-T T 20/17.2
C68 4030017460 S.CER ECJ0EB1E102K T 1.2/26.5
C69 4030017460 S.CER ECJ0EB1E102K T 1.6/38.1
C70 4030017490 S.CER C1608 JB 1A 105K-T T 20.9/37.9
C71 4030017460 S.CER ECJ0EB1E102K T 19.2/37.5
C72 4030016930 S.CER ECJ0EB1A104K B 24.4/19.1
C73 4030016930 S.CER ECJ0EB1A104K T 25.7/38.9
C74 4030017620 S.CER ECJ0EC1H100C T 23.6/32.2
C75 4030016930 S.CER ECJ0EB1A104K T 24.8/32.7
C76 4030017460 S.CER ECJ0EB1E102K B 4.9/18.8
C77 4030017460 S.CER ECJ0EB1E102K T 24.8/27.2
C78 4030017460 S.CER ECJ0EB1E102K B 10.3/21.3
C79 4030017460 S.CER ECJ0EB1E102K T 18.9/38.7
C80 4030017460 S.CER ECJ0EB1E102K T 9.3/21.3
C81 4030017460 S.CER ECJ0EB1E102K T 10.3/13.3
C82 4550007070 S.TAN TEESVP 1A 475M8R T 2.8/21.9
C83 4030016790 S.CER ECJ0EB1C103K B 17.4/39.7
C84 4030016930 S.CER ECJ0EB1A104K T 4.9/21.5
C86 4030017460 S.CER ECJ0EB1E102K B 1.2/37.9
C88 4030017730 S.CER ECJ0EB1E471K B 1.4/23.1
C89 4030017490 S.CER C1608 JB 1A 105K-T B 2.9/21.9
C90 4030017730 S.CER ECJ0EB1E471K B 1.5/24.8
C91 4030017730 S.CER ECJ0EB1E471K B 4.8/4.9
C92 4030016930 S.CER ECJ0EB1A104K T 22/31.6
C93 4030017380 S.CER ECJ0EC1H050B T 21.1/29.9
C94 4030016930 S.CER ECJ0EB1A104K T 23.9/27.2
J1 6510018440 S.CNR AXN430C330P T 13.2/4.3
