This service manual describes the latest service information
for the IC-PCR1500 and IC-PCR2500 COMMUNICATIONS
RECEIVERS at the time of publication.
Be sure to include the following four points when ordering
replacement parts:
1. 10-digit Icom parts numbers
2. Component name and informations
3. Equipment model name and unit name
4. Quantity required
<SAMPLE ORDER>
1110001811 S.IC TA7S04F IC-PCR2500 Main-A unit 5 pieces
8810008960 Screw FH M2.6 IC-PCR2500 Chassis 8 pieces
Addresses are provided on the inside back cover for your
convenience.
NEVER connect the receiver to an AC outlet or to a DC
power supply that uses more than 16 V. Such a connection
could cause a fire hazard and/or electric shock.
DO NOT expose the receiver to rain, snow or any liquids.
DO NOT reverse the polarities of the power supply when
connecting the receiver.
DO NOT apply an RF signal of more than 20 dBm (100 mW)
to the antenna connector. This could damage the receiver’s
front end.
1. Make sure a problem is internal before disassembling
the receiver.
2. DO NOT open the transceiver until the receiver is
disconnected from its power source.
3. DO NOT force any of the variable components. Turn
them slowly and smoothly.
4. DO NOT short any circuits or electronic parts. An
insulated turning tool MUST be used for all adjustments.
5. DO NOT keep power ON for a long time when the
receiver is defective.
6. READ the instructions of test equipment thoroughly
before connecting equipment to the receiver.
To upgrade quality, any electrical or mechanical parts
and internal circuits are subject to change without
notice or obligation.
Icom, Icom Inc. and logo are registered trademarks of Icom Incorporated (Japan) in the United States, the United
Kingdom, Germany, France, Spain, Russia and/or other countries.
INTRODUCTION CAUTION
ORDERING PARTS
REPAIR NOTES
MODEL VERSION SYMBOL
IC-PCR1500
IC-PCR2500
Europe EUR-1
U.K. UK-1
U.S.A. USA-1
Canada CAN-1
France FRA-1
South East Asia SEA-1
Export
EXP-2
EXP-3
IC-PCR2500* U.S.A. USA-3
*UT-122 is already installed as DIGITAL UNIT.
(IC-PCR2500)
