Icom IC-R30 Service Manual

4-3
4-2 ADJUSTMENT
ADJUSTMENT
ADJUSTMENT DISPLAY
SETTING CONDITION VALUE
ITEM FREQUENCY MODE SUB
Reference
frequency
0 A REF1 1304.490 FM – Connect the spectrum analyzer to the antenna
connector and set it to:
Span: 1 kHz
RBW: 30 Hz
VBW: 30 Hz
1038.25 MHz
±50 Hz
1 A REF2 1304.490 FM –
WFM S
curve
2 A WFM 1304.900 WFM – Connect the standard signal generator to the
antenna connector and set it to:
Frequency: 1304.900 MHz
Modulation: Non
Level: +60 dBµ (–47 dBm)
Push
[ENTER].
(Automatic
adjustment)
AFC 3 A AFC1 1304.900 FM –
4 B AFC2 519.900 FM – Set the standard signal generator to:
Frequency: 519.900 MHz
BPF 5 B BPFL 108.020 FM – Set the standard signal generator to:
Frequency: The same as the displayed
frequency.
6 B BPFM 144.020 FM –
7 B BPFH 173.980 FM –
8 B BPFL 174.020 FM –
9 B BPFM 217.000 FM –
10 B BPFH 259.980 FM –
11 B BPFL 260.020 FM –
12 B BPFM 320.020 FM –
13 B BPFH 379.980 FM –
14 B BPFL 380.020 FM –
15 B BPFM 450.020 FM –
16 B BPFH 519.980 FM –
S-meter
curve
17 A SC0 14 5.10 0 FM 14 5.10 0 Set the standard signal generator to:
Frequency: 145.100 MHz
Level: –10 dBµ (–117 dBm)
18 B SC0 145.10 0 FM 145.10 0
19 A SC3 145.10 0 FM 145.10 0 Set the standard signal generator to:
Level: –6 dBµ (–113 dBm)
20 B SC3 145.10 0 FM 14 5.10 0
21 A SCF 145.10 0 FM 14 5.10 0 Set the standard signal generator to:
Level: +5 dBµ (–102 dBm)
22 B SCF 145.10 0 FM 145.10 0
23 A SC0 145.10 0 WFM 145.10 0 Set the standard signal generator to:
Level: +7 dBµ (–100 dBm)
24 A SC3 14 5.10 0 WFM 145.100 Set the standard signal generator to:
Level: +11 dBµ (–96 dBm)
25 A SCF 145.100 WFM 145.100 Set the standard signal generator to:
Level: +25 dBµ (–82 dBm)
26 A SC0 145.100 LSB 14 5.10 0 Set the standard signal generator to:
Frequency: 145.0985 MHz
Level: –10 dBµ (–117 dBm)
27 A SC3 145.10 0 LSB 145.100 Set the standard signal generator to:
Level: –6 dBµ (–113 dBm)
28 A SCF 145.100 LSB 14 5 .10 0 Set the standard signal generator to:
Level: +5 dBµ (–102 dBm)
S-meter
(S3)
29 A S3 22.500 FM 14 5.10 0 Set the standard signal generator to:
Frequency: The same as the displayed
frequency on the MAIN band.
Level: –6 dBµ (–113 dBm)
30 A S3 40.10 0 FM 145.10 0
31 A S3 63.10 0 FM 63.100
32 A S3 92.10 0 FM 145.100
33 A S3 217.10 0 FM 217.10 0
34 B S3 217.10 0 FM 217.10 0
35 A S3 320.100 FM 32 0.10 0
36 B S3 320.10 0 FM 320.10 0
37 A S3 470.100 FM 470.100
38 B S3 470.100 FM 470.10 0
39 A S3 65 0.10 0 FM 145.100
40 A S3 1167. 50 0 FM 14 5.10 0
41 A S3 2341.10 0 FM 145.10 0 Set the standard signal generator to:
Level: +2 dBµ (–105 dBm)
