6-1
[CHASSIS UNIT] [LOGIC UNIT] (for #12 and #20)
[MAIN UNIT]
REF
NO.
PART
NO.
DESCRIPTION QT Y.
REF
NO.
PART
NO.
DESCRIPTION QT Y.
REF
NO.
PARTS
NO.
DESCRIPTION QT Y.
*: Refer to "BOARD LAYOUTS" for the location.
Screw abbreviations A, B0, BT: Self-tapping PH: Pan head BS: Brass NI: Nickel ZU: Zinc SUS: Stainless
J1 6510032720 3754 ANT CONNECTOR 1
SP1 2510002150 C36N07M-7 1
W1 8900016360 OPC-1190A 1
EP1 3310005180 GNBA-A13B (031015271EI1000 1
EP2 8940000120 3754 KEY P.C.B. 1
MP1 8210033780 3754 REAR PANEL (A) ASSEMBLY [#12] 1
8210033050 3754 REAR PANEL ASSEMBLY [#16] 1
8210033050 3754 REAR PANEL ASSEMBLY [#20] 1
MP2 8930084870 3384 REAR SHEET 1
MP3 8930030920 1301 SHEET 1
MP4 8930063280 DOUBLE SIDE TAPE (AP) 1
MP5 8930060200 HIMELON SHEET (CJ) 1
MP6 8930095450 3822 SPONGE 1
MP7 8930099180 3754 ANT PLATE 1
MP9 8930089520 3484 GPS SPONGE 1
MP14 8930097260 3754 JACK CAP (KOB) 1
MP15 8850003250 PLAIN WASHER (AU) 1
MP16 8810011360 TRUSS B0 2×5 SUS SSBC 1
MP18 8930069020 O-RING (BG) 1
MP19 8830000571 STEP NUT (A)-1 1
MP20 8610016380 KNOB N-451 1
MP21 8930097250 3754 SD CAP (KOB) 1
MP22 8930051390 2304 SHAFT 1
MP23 8310091290 3754 LOCK PLATE 1
MP24 8930096840 3699 CONTACT RUBBER (TOP) 1
MP25 8810009181 FLAT BT M2×5 NI-ZC3 1
MP26 8810009181 FLAT BT M2×5 NI-ZC3 5
MP27 8810009181 FLAT BT M2×5 NI-ZC3 6
MP28 8810009181 FLAT BT M2×5 NI-ZC3 5
MP29 8210033030 3754 FRONT PANEL ASSEMBLY 1
MP31 8930097240 3754 MAIN SEAL (YG) 1
MP32 8310091150 3699 WINDOW PLATE 1
MP33 8930096850 3699 WINDOW SHEET 1
MP34 8930090100 O-RING (CX) (TOT) 1
MP35 8930099230 3754 SP HOLDER 1
MP36 8810009181 FLAT BT M2×5 NI-ZC3 2
MP37 8950009410 3766 T-KEY (F) (YTP) 1
MP39 8820001510 3062 SCREW 6
MP40 8930063690 O-RING (BA) (TOP) 6
MP41 8930059290 O-RING (AU) (TOP) 1
MP42 8830003660 STEP NUT (M) 1
MP44 8810000101 PH M2×4 ZK3 1
MP46 8930099210 3754 ANT EARTH PLATE 1
MP47 8930099190 3754 A-EARTH PLATE 1
MP48 8930099220 3754 B-EARTH PLATE 1
MP49 8930098420 SPONGE (PK) 1
MP51 8930093160 SPONGE (NS) 1
MP52 8930099530 SPONGE (PR) 1
MP53 8930099540 SPONGE (PS) 2
MP55 8930059331 SHIELD SPONGE (W)-1 Only [#12] 1
MP56 8930070581 SHIELD SPONGE (BA)-1 Only [#12] 1
MP57 8930070581 SHIELD SPONGE (BA)-1 Only [#12] 1
MP58 8930085111 SHIELD SPONGE (CX)-1 Only [#12] 1
MP59 8930100100 3754 INSULATION SHEET Only [#12] 1
J1* 6510031380 31FXVL-RSM1-GAN-TF-1 (HF) 1
J2* 6510028170 SDHL-8BNS-K-363-A0-ETB (HF) 1
J3* 6510023480 AYU1-1P-02676-120-TF 1
J4* 6510032320 50P4.0-JMCS-G-TF (N) 1
J6* 6510031390 15FXVL-RSM1-GAN-TF-1 (HF) 1
DS4 5030004360 TM128160D1CIWUGND 1
S1 2250001070 ED09D21OFD14.0S6.0C20G 1
BT1* 3020000390 ML414HIV01E 1
EP100 6910027670 AS-G125A2BACAD-AA 1
MP1* 8510022450 3754 GPS CASE 1
MP2 8930099300 SHIELD TAPE (AG) 1
MP3 8930099310 SHIELD TAPE (AH) 1
MP4 8930099250 3754 LOGIC PLATE 1
MP5 8210032890 3699 REFLECTOR 1
MP6 8930096860 3699 WHITE SHEET 1
MP7 8930096870 3699 LCD FILTER 1
MP8 8930099240 3754 LCD HOLDER 1
MP9 8930094680 DOUBLE SIDE TAPE (CC) 2
MP10 8930083700 DOUBLE SIDE TAPE (BM) 1
MP11 8930098430 SPONGE (PL) 2
MP12 8930099610 3754 LCD SHEET 1
MP200* 8510022430 3754 DSP CASE 1
J1000* 6510030041 CSS5005-4R11FSZ 1
J1001* 6510021901 BM02B-ASRS-TF (LF) (SN) 1
J1002* 6510030220 50RF-JMCS-G-1B-TF (N) (LF) (SN) 1
J1003* 6510027390 40FHY-RSM1-GAN-TF (LF) (SN) 1
S1000* 2260003320 SKRTLAE010 1
S1001* 2260003320 SKRTLAE010 1
S1002* 2260003320 SKRTLAE010 1
S1003* 2260003320 SKRTLAE010 1
EP1 3310004220 KY-058-007-01 1
MP1000 8950009230 3699 CONTACT SPRING 1
MP1001* 8510022420 3754 PLL CASE 1
MP1002* 8510022420 3754 PLL CASE 1
MP1003* 8510022440 3754 REF CASE 1
MP1004* 8510022460 3754 A-VCO CASE 1
MP1005* 8510022490 3754 G-VCO CASE 1
MP1006 8510022400 3754 S-SHIELD PLATE 1
MP1007 8510022500 3754 MAIN SHIELD PLATE 1
MP1008 8930099320 SHIELD TAPE (AI) 1
MP1009 8930099320 SHIELD TAPE (AI) 1
MP1010 8930099290 SHIELD TAPE (AE) 1
MP1011 8930099340 SHIELD TAPE (AK) 1
MP1012 8930099330 SHIELD TAPE (AJ) 1
MP1013 8930099380 3754 MAIN SPONGE 1
MP1014 8930099390 3754 SPONGE 1
MP1015 8930099530 SPONGE (PR) 1
MP1016 8930070581 SHIELD SPONGE (BA)-1 Only [#12] 1
MP1017 8930097440 FERRITE SHEET (BH) Only [#12] 1
MP1018 8930088330 FERRITE SHEET (AM) Only [#12] 1
MP1019 8930085101 SHIELD SPONGE (CW)-1 Only [#12] 1
MP1020 8930100120 FERRITE SHEET (BM) Only [#12] 1
MP1021 8930058510 INSULATION SHEET (HC) Only [#12] 1
SECTION 6 MECANICAL PARTS
[AF UNIT]
REF
NO.
PART
NO.
DESCRIPTION QT Y.
J1* 6510027390 40FHY-RSM1-GAN-TF (LF) (SN) 1
J2 6450002530 HSJ4456-010320 1
W1 7030014230 RJ20S0OHM 1
W2 8900014871 OPC-1332A-1 (P0.5N40L100) 1
MP1 8930099200 3754 AF PLATE 1
MP2 8930100110 SPONGE (PU) Only [#12] 1
