9
3
BATTERY PACKS
■ Battery pack replacement
Before replacing the battery pack, push [POWER] for 1 sec. to turn
the power OFF.
• Slide the battery release forward, then pull the battery pack up-
ward with the transceiver facing away from you.
DD
BATTERY PACKS
*
1
Operating periods are calculated under the following conditions;
Tx : Rx : standby =5 : 5 : 90, power save function: auto setting is activated
*
2
Operating period depends on the alkaline cells used.
Charging period
Battery
Voltage Capacity
BC-144
Battery life*
1
pack BC-146 or
BC-121
BP-208
Battery case for AA
N/A N/A —*
2
(R6)×6 alkaline
BP-209 7.2 V 1100 mAh 12 hrs. 1.5 hrs. 7.5 hrs.
BP-210 7.2 V 1650 mAh 18.5 hrs. 2.0 hrs. 11 hrs
BP-222 7.2 V 600 mAh 6.5 hrs. 1.0 hr. 4 hrs
