SCAN OPERATION
■ Programmed scan
Programmed scan repeatedly scans between two user pro-
grammed frequencies (memory channels “1A–3A” and “1b–3b”) or
scans between upper and lower band edges. This scan is useful
for checking for signals within a specific frequency range such as
repeater output frequencies, etc.
q Push [D•
CLR
] to select VFO mode, if necessary.
w Push [5•
SCAN
] after pushing [A•
FUNC
] to start the scan, then a
selected scan edge appears as “P1”, “P2”, “P3” or “AL.”
• To change the scan edge, push [8•
SET
] after pushing [A•
FUNC
] sev-
eral times until the desired scan edge appears.
• “AL” for full scan, “P1”, “P2” and “P3” for programmed scan be-
tween the programmed scan edge channels as “1A”–“1b”,
“2A”–“2b” and “3A”–“3b”.
• To change the scan direction, push [Y] or [Z].
• When “dial” is assigned [VOL], rotate [VOL] to change the scan di-
rection. (p. 50)
e Push [D•
CLR
] to stop the scan.
NOTE: Scan edges, 1A–3A/1b–3b, must be programmed in ad-
vance.
Program them in the same manner as regular memory chan-
nels. (p. 24)
If the same frequencies are programmed into the scan edges,
programmed scan will not proceed.
