Icom IC-T7H Service Manual

S.=Surface mount
IC250 1110002700 S.IC NJM2904M-T1
IC851 1130007610 S.IC µPD3140GS-E1 (DS8)
Q201 1530000371 S.TRANSISTOR 2SC3356 R25-T2B
Q202 1510000670 S.TRANSISTOR 2SA1588-GR (TE85R)
Q203 1590001140 S.TRANSISTOR UN9210 (TX)
Q204 1590002730 S.TRANSISTOR UN921L (TX)
Q250 1530002280 S.TRANSISTOR 2SC4081 T107 S
Q253 1590001050 S.TRANSISTOR DTC114TUA T106
Q255 1520000430 S.TRANSISTOR 2SB1462-R (TX)
Q351 1530003310 S.TRANSISTOR 2SC5107-O (TE85R)
Q352 1530003310 S.TRANSISTOR 2SC5107-O (TE85R)
Q353 1590001690 S.TRANSISTOR UN9115 (TX)
Q354 1590001140 S.TRANSISTOR UN9210 (TX)
Q355 1560000540 S.FET 2SK880-Y (TE85R)
Q356 1530002280 S.TRANSISTOR 2SC4081 T107 S
Q357 1590001690 S.TRANSISTOR UN9115 (TX)
Q701 1530000371 S.TRANSISTOR 2SC3356 R25-T2B
Q702 1520000460 S.TRANSISTOR 2SB1132 T100 R
Q703 1540000350 S.TRANSISTOR 2SD2216-S (TX)
Q704 1590001150 S.TRANSISTOR UN9211 (TX)
Q705 1510000670 S.TRANSISTOR 2SA1588-GR (TE85R)
Q852 1530002560 S.TRANSISTOR 2SC4403-3-TL
Q853 1590001690 S.TRANSISTOR UN9115 (TX)
Q854 1590001140 S.TRANSISTOR UN9210 (TX)
D1 1790001260 S.DIODE MA2S077-(TX)
D2 1790001260 S.DIODE MA2S077-(TX)
D51 1790001260 S.DIODE MA2S077-(TX)
D52 1790001260 S.DIODE MA2S077-(TX)
D201 1790001260 S.DIODE MA2S077-(TX)
D202 1790001260 S.DIODE MA2S077-(TX)
D250 1730002260 S.ZENER MA8030-H (TX)
D251 1790001010 S.ZENER MA8043-L (TX)
D351 1790001260 S.DIODE MA2S077-(TX)
D352 1790001260 S.DIODE MA2S077-(TX)
D353 1790001260 S.DIODE MA2S077-(TX)
D354 1790000840 S.DIODE MA132WA (TX)
D551 1790001260 S.DIODE MA2S077-(TX)
D552 1790001260 S.DIODE MA2S077-(TX)
D701 1790001260 S.DIODE MA2S077-(TX)
D702 1790000860 S.DIODE MA133 (TX)
D703 1790001250 S.DIODE MA2S111-(TX)
D722 1750000530 S.DIODE 1SV271 (TPH3)
D723 1790001260 S.DIODE MA2S077
D724 1790001260 S.DIODE MA2S077
D725 1750000530 S.DIODE 1SV271 (TPH3)
D901 1750000540 S.DIODE RB060L-40 TE-25
X851 6050009430 XTAL CR-515 (15.200000 MHz)
L1 6200007790 S.COIL LQN21A R15J04
L2 6200008250 S.COIL 0.30-0.9-7TL 21N
L3 6200008760 S.COIL 0.26-0.9-9TR 30N
L5 6200004350 S.COIL LL1608-F10NK
L6 6200004350 S.COIL LL1608-F10NK
L7 6200008240 S.COIL 0.30-0.9-5TL 14N
L8 6200008850 S.COIL 0.40-1.1-6TR
L9 6200008770 S.COIL 0.28-1.0-5TR 16N
L10 6200005890 S.COIL NLH252018T-039J 39N
L11 6200008830 S.COIL 0.20-1.0-12TL 60N
L12 6200005900 S.COIL NLH252018T-047J 47N
L13 6200004480 S.COIL MLF1608D R82K-T
L51 6200005910 S.COIL NLH252018T-056J 56N
L52 6200005910 S.COIL NLH252018T-056J 56N
L201 6200004480 S.COIL MLF1608D R82K-T
L202 6200005930 S.COIL NLH252018T-082J 82N
L203 6200003590 S.COIL EXCCL3225U1
L204 6200003590 S.COIL EXCCL3225U1
L205 6200004480 S.COIL MLF1608D R82K-T
L206 6200005690 S.COIL ELJRE 18NG-F
L352 6200003550 S.COIL MLF1608A 4R7K-T
L353 6200003550 S.COIL MLF1608A 4R7K-T
L354 6200004480 S.COIL MLF1608D R82K-T
L355 6200004480 S.COIL MLF1608D R82K-T
L551 6200008530 S.COIL 0.30-1.0-4TR 12N
L552 6200008530 S.COIL 0.30-1.0-4TR 12N
L701 6200004370 S.COIL LL1608-F15NK
L702 6200005830 S.COIL NLH252018T-012J 12N
L703 6200004380 S.COIL LL1608-F18NK
L723 6200008080 S.COIL LQN21A R22J04
L724 6200008080 S.COIL LQN21A R22J04
L725 6200008080 S.COIL LQN21A R22J04
L801 6200006980 S.COIL ELJRE R10G-F
L900 6200003590 S.COIL EXCCL3225U1
L901 6200003590 S.COIL EXCCL3225U1
R1 7030007270 S.RESISTOR ERJ2GEJ 151 X (150 Ω)
R201 7030004980 S.RESISTOR ERJ2GEJ 101 X (100 Ω)
R202 7030007270 S.RESISTOR ERJ2GEJ 151 X (150 Ω)
R203 7030005040 S.RESISTOR ERJ2GEJ 472 X (4.7 kΩ)
R204 7030005530 S.RESISTOR ERJ2GEJ 100 X (10 Ω)
R205 7030007340 S.RESISTOR ERJ2GEJ 153 X (15 kΩ)
R207 7030005040 S.RESISTOR ERJ2GEJ 472 X (4.7 kΩ)
R208 7030004980 S.RESISTOR ERJ2GEJ 101 X (100 Ω)
R209 7030005040 S.RESISTOR ERJ2GEJ 472 X (4.7 kΩ)
R210 7030004980 S.RESISTOR ERJ2GEJ 101 X (100 Ω)
R250 7030007330 S.RESISTOR ERJ1WRSJR15U (0.15 Ω)
R251 7030005070 S.RESISTOR ERJ2GEJ 683 X (68 kΩ)
R252 7030005240 S.RESISTOR ERJ2GEJ 473 X (47 kΩ)
R258 7030007340 S.RESISTOR ERJ2GEJ 153 X (15 kΩ)
R259 7030005050 S.RESISTOR ERJ2GEJ 103 X (10 kΩ)
R260 7030004980 S.RESISTOR ERJ2GEJ 101 X (100 Ω)
R261 7030005160 S.RESISTOR ERJ2GEJ 105 X (1 MΩ)
R262 7030005220 S.RESISTOR ERJ2GEJ 223 X (22 kΩ)
R263 7030005050 S.RESISTOR ERJ2GEJ 103 X (10 kΩ)
R264 7030007290 S.RESISTOR ERJ2GEJ 222 X (2.2 kΩ)
R265 7030005040 S.RESISTOR ERJ2GEJ 472 X (4.7 kΩ)
R266 7510001000 S.THERMISTOR TBPS1R154K475H5Q
R267 7030007340 S.RESISTOR ERJ2GEJ 153 X (15 kΩ)
R278 7030005530 S.RESISTOR ERJ2GEJ 100 X (10 Ω)
R281 7030005120 S.RESISTOR ERJ2GEJ 102 X (1 kΩ)
R282 7030005090 S.RESISTOR ERJ2GEJ 104 X (100 kΩ)
R283 7030005090 S.RESISTOR ERJ2GEJ 104 X (100 kΩ)
R284 7030007260 S.RESISTOR ERJ2GEJ 330 X (33 Ω)
R285 7030005120 S.RESISTOR ERJ2GEJ 102 X (1 kΩ)
R350 7030005120 S.RESISTOR ERJ2GEJ 102 X (1 kΩ)
R351 7030009200 S.RESISTOR ERJ2GEJ 390 X (39 Ω)
R352 7030005030 S.RESISTOR ERJ2GEJ 152 X (1.5 kΩ)
R354 7030005220 S.RESISTOR ERJ2GEJ 223 X (22 kΩ)
R355 7030007260 S.RESISTOR ERJ2GEJ 330 X (33 Ω)
R356 7030005300 S.RESISTOR ERJ2GEJ 150 X (15 Ω)
R357 7030005300 S.RESISTOR ERJ2GEJ 150 X (15 Ω)
R358 7030004980 S.RESISTOR ERJ2GEJ 101 X (100 Ω)
R359 7030005240 S.RESISTOR ERJ2GEJ 473 X (47 kΩ)
R360 7030004990 S.RESISTOR ERJ2GEJ 221 X (220 Ω)
R361 7030004970 S.RESISTOR ERJ2GEJ 470 X (47 Ω)
R362 7030005100 S.RESISTOR ERJ2GEJ 154 X (150 kΩ)
R363 7030005110 S.RESISTOR ERJ2GEJ 224 X (220 kΩ)
R364 7030005110 S.RESISTOR ERJ2GEJ 224 X (220 kΩ)
R365 7030007280 S.RESISTOR ERJ2GEJ 331 X (330 Ω)
R366 7030005050 S.RESISTOR ERJ2GEJ 103 X (10 kΩ)
R367 7030005030 S.RESISTOR ERJ2GEJ 152 X (1.5 kΩ)
R368 7030005010 S.RESISTOR ERJ2GEJ 681 X (680 Ω)
R369 7030005090 S.RESISTOR ERJ2GEJ 104 X (100 kΩ)
R370 7030005050 S.RESISTOR ERJ2GEJ 103 X (10 kΩ)
R371 7030007280 S.RESISTOR ERJ2GEJ 331 X (330 Ω)
R372 7030005090 S.RESISTOR ERJ2GEJ 104 X (100 kΩ)
R373 7030005240 S.RESISTOR ERJ2GEJ 473 X (47 kΩ)
R374 7030005090 S.RESISTOR ERJ2GEJ 104 X (100 kΩ)
R701 7030005040 S.RESISTOR ERJ2GEJ 472 X (4.7 kΩ)
R702 7030005040 S.RESISTOR ERJ2GEJ 472 X (4.7 kΩ)
R704 7030005530 S.RESISTOR ERJ2GEJ 100 X (10 Ω)
R705 7030005050 S.RESISTOR ERJ2GEJ 103 X (10 kΩ)
R706 7030004980 S.RESISTOR ERJ2GEJ 101 X (100 Ω)
6 - 1
REF ORDER
DESCRIPTION
NO. NO.
[1F UNIT]
REF ORDER
DESCRIPTION
NO. NO.
[1F UNIT]
SECTION 6 PARTS LIST
