4
PS5R-V Switching Power Supplies
Specifications
Part No.
(10W/15W)
PS5R-VB05
PS5R-VB12
PS5R-VB24
(30W)
PS5R-VC12
PS5R-VC24
(60W)
PS5R-VD24
(90W)
PS5R-VE24
(120W)
PS5R-VF24
(240W)
PS5R-VG24
Input
Rated Input Voltage
(Single-phase two-wire)*
1
100 to 240V AC
(Voltage range: 85 to 264V AC/100 to 370V DC) (Load ≤ 80% at 100-105V DC)
Frequency 50/60 Hz
Input
Current
(Typ.)
100V AC
5V: 0.25A
12V, 24V: 0.35A
0.7A 1.3A 1.1A 1.4A 2.7A
230V AC
5V: 0.14A
12V, 24V: 0.19A
0.3A 0.8A 0.6A 0.7A 1.2A
Inrush
Current
(Typ.)
100V AC
18A (Ta = 25°C, cold start)
14A max.
(Ta = 25°C, cold start)
230V AC
45A (Ta = 25°C, cold start)
30A max.
(Ta = 25°C, cold start)
Leakage
Current
120V AC
0.5 mA max.
230V AC
1.0 mA max.
Efciency
(Typ.)
(at rated
output)*
2
100V AC
5V: 77%, 12V: 82%, 24V: 84%
12V: 83%, 24V: 85% 86% 88% 89%
230V AC
5V: 73%, 12V: 80%, 24V: 81%
12V: 85%, 24V: 87% 86% 89% 90%
Power
Factor (Typ.)
100V AC
— — — 0.99
230V AC
— — — 0.86 0.92 0.96
Output
Rated Voltage/Current
5V/2.0A*
3
, 12V/1.3A,
24V/0.65A
12V/2.5A, 24V/1.3A 24V/2.5A 24V/3.75A 24V/5A 24V/10A
Adjustable Voltage
Range
±10% ±5% ±10%
Output
Holding Time
(Typ.)
(at rated output)
100V AC
5V: 53ms, 12V: 34ms,
24V: 36ms
12V: 13ms, 24V: 15ms 13ms 20ms 30ms 30ms
230V AC
5V: 330ms
12V: 215ms
24V: 230ms
12V: 110ms
24V: 110ms
105ms 30ms 33ms 40ms
Start Time (at rated
input and output)
500 ms max. 600 ms max. 800 ms max. 700 ms max. 800 ms max.
Rise Time (at rated
input and output)
5V, 12V: 200ms max.
24V: 250ms max.
200ms max.
Regulation
Input Fluctuation 0.4% max.
Load Fluctuation
5V: 2.5% max.
12V, 24V: 1.0% max.
1.0% max.
Temperature
Change
0.05%/C max. (–10 to +65C )
12V: 0.05%/C max. (–10 to +50C)
24V: 0.05%/C max. (–10 to +55C)
0.05%/C max. (–10 to +55C ) 0.05%/C max. (–25 to +55C )
Ripple
(including noise)
5V: 8% p-p max. (–25 to –10C)
12V: 6% p-p max. (–25 to –10C)
24V: 4% p-p max. (–25 to –10C)
12V: 6% p-p max. (–25 to –10C)
24V: 4% p-p max. (
–25 to –10C)
4% p-p max. (–25 to –10C) 4% p-p max. (–25 to –10C)
5V: 5% p-p max. (–10 to +0C)
12V: 2.5% p-p max. (–10 to +0C)
24V: 1.5% p-p max. (–10 to +0C)
12V: 2.5% p-p max. (–10 to +0C)
24V: 1.5% p-p max. (
–10 to +0C)
1.5% p-p max. (–10 to +0C) 1.5% p-p max. (–10 to +0C)
5V: 2.5% p-p max. (0 to +65C)
12V: 1.5% p-p max. (0 to +65C)
24V: 1% p-p max. (0 to +65C)
12V: 1.5% p-p max. (0 to +50C)
24V: 1% p-p max. (0 to +55C)
1% p-p max. (0 to +55C) 1% p-p max. (0 to +55C)
Supple-
mentary
Functions
Overcurrent
Protection
105% min. (auto reset) 101% min. (auto reset) 105% min. (auto reset)
Operation
Indicator
LED (green)
Dielectric Strength
Between input and output terminals: 3,000V AC, 1 minute
Between input and ground terminals: 2,000V AC, 1 minute
Between output and ground terminal: 500V AC, 1 minute
Insulation Resistance Between input and output terminals: 100M min. (500V DC megger), Between input and ground terminal: 100M min. (500V DC megger)
Operating Temperature*
4
–25 to +75°C (no freezing)
–25 to +70°C (no freezing) –25 to +65°C (no freezing)
Operating Humidity 20 to 90% RH (no condensation)
Storage Temperature –25 to +75°C (no freezing)
Storage Humidity 20 to 90% RH (no condensation)
Vibration Resistance
10 to 55 Hz, amplitude 0.375mm,
2 hours each in 3 axes
(when used with part no. BNL6 mounting clips)
10 to 55 Hz, amplitude 0.33mm, 2 hours each in 3 axes
(when used with part no. BNL6 mounting clips)
10 to 55 Hz, amplitude 0.375mm, 2 hours each in 3
axes (when used with part no. BNL8 mounting clips)
10 to 55 Hz, amplitude
0.21mm, 2 hours each in 3
axes (when used with part
no. BNL6 mounting clips)
10 to 55 Hz, amplitude
0.375mm, 2 hours each in 3
axes (when used with part
no. BNL8 mounting clips)
10 to 55 Hz, amplitude
0.375mm, 2 hours each
in 3 axes
(when used with part no.
BNL6 mounting clips)
Shock Resistance 300 m/s
2
, 3 times each in 6 directions
EMC
EMI EN61204-3 (Class B)
EMS EN61204-3 (industrial)
Safety Standards
UL508 (Listing), UL1310 Class 2, ANSI/ISA-12.12.01, CSA C22.2 No. 107.1, 213, 223
EN60950-1, EN50178
UL508 (Listing), ANSI/ISA-12.12.01
CSA C22.2 No. 107.1, 213, EN60950-1, EN50178
Other Standard SEMI F47 (at 208V AC input only)
Degree of Protection IP20 (EN60529)
Dimensions (mm) 90H × 22.5W × 95D 95H × 36W × 108D 115H × 46W × 121D 125H × 60W × 125D
Weight (approx.) 140g 150g 260g 310g 470g 960g
Terminal Screw M3.5
At normal temperature and humidity unless otherwise specied.
*1: DC input voltage is not subject to safety standards. When using on DC input, connect a fuse to the input terminal for DC input protection.
*2: Under stable state. *3: PS5R-VB05 (5V DC/2.0A) is 10W (Up to 3.0A at Ta = 0 to 40°C. Not subject to safety standards at 2.0A and over.)
*4: See the output derating curves on page 5.
Reference Value
Expected Life*
5
8 years minimum (at the rated input, 50% load, operating temperature +40°C, standard mounting direction)
*5: Calculation of the expected life is based on the actual life of the aluminum electrolytic capacitor. The expected life depends on operating conditions.
