APPENDIX A - Technical Specification
C-thrue
SYSTEM SPECIFICATIONS
Antenna Center Frequency
2.0 GHz
Number of Antennas
Antenna Polarisation
Horizontal and Vertical
Number of Radar Channels
2
Scan Interval
Up to 10 scans/cm
Depth Range
Up to 80 cm (up to 31.5 in.)
Display modes
B-Scan and C-scan (radar tomography)
Positioning system
“Virtual Pad” (based on 3 High safety - Class 1
laser sensors with reflective bars)
AC Power Conduits Detection
EM sensor integrated (50/60 Hz)
Battery
Li-ion battery, 15V, 3.2Ah, 2-hour runtime
Data Storage
32 GB
Connectivity
USB, Wi-Fi
ENVIRONMENTAL SPECIFICATIONS
Operating Temperature
-20°C to +50°C (-4°F to +122°F)
Storage Temperature
-40°C to +60°C (-40°F to +140°F)
Environmental
IP65
MECHANICAL SPECIFICATIONS
Dimensions (length x width x
height)
285mm x 200mm x 160mm (11,2in x 8,6in x
6,3in)
Weight
2.4 kg (5 lb) with battery
Display
7.0 inches
TFT multi-touch
SOFTWARE SPECIFICATIONS
C-thrue software
Quick start-up
Real time radar data acquisition, processing and
visualization in B-Scan
Real time feature marking, management and
editing tool
Rebar/Void automatic discrimination
VirtualPad - Positioning & navigation system
Visualization of C-scan (radar tomography)
Real time diagnose of radar and the other
devices
Metric and imperial units
Available in more than 20 languages
First rebar layer automatic detection
Automatic job reports
Real time Power conduit sensing display
ACCESSORIES SPECIFICATIONS
C-thrue External Controller
Remote control of C-thrue
Representation of results in Augmented Reality
(when used with Virtual Pad)
Display: 10.1 inches
Drop resistant: 1.8 m (5.9 ft)
Connectivity: 4G LTE, Wi-Fi
Environmental: MIL- STD 810G and IP65
C-thrue Handle
Aluminum handle
1.5 m (5 ft)
Remote control buttons

IDS C-Thrue Specifications

General

Brand	IDS
Model	C-Thrue
Category	Radar
Language	English
