COMCO IKARUS
Maintenance Manual C42 Series
MaintenanceManual C42-
Series_Issue_VII_18.02.2014.doc
Revison No.:1 39 from 107
2.8.7 Carburettor control
The throttle is controlled by 2 throttle levers via Bowden cables. The choke is also
actuated via a central pull-knob and Bowden cables.
Figure 44: Carburettor controls C42 / C42B
Figure 45: Carburettor controls C42 UK / C42B UK / C42 E
choke Bowden
cable
throttle valve
