COMCO IKARUS
Maintenance Manual C42 Series
MaintenanceManual C42-
Series_Issue_VII_18.02.2014.doc
Revison No.:1 69 from 107
shock absorber
pressure valve
4.3.3 Landing gear
4.3.3.1 Greasing the nose wheel fork bearing
The nose wheel fork bearing in the nose wheel spar must be greased. Using a
grease gun, grease is pressed in via the grease nipples above and below the nose
wheel spar.
Figure 60: Grease nipples, nose wheel landing gear
4.3.3.2 Checking and setting the shock absorbers
The spring stiffness of the main landing gear can be adjusted via the shock
absorbers. Air pressure can be adjusted by means of a special high pressure pump.
IFC / ISC are equipped with such a pump. It can also be ordered from COMCO
IKARUS GmbH, parts number 01798.
air pressure, shock absorber: 28,0 – 34,0 bar 400 - 490 PSI
amount of oil 200 ml
hydraulic oil HVP 10
Attention: Do not use a standard
automobile air pump.
Figure 61: Shock absorbers
lower grease
upper grease
