IKEA koppla User Manual

32
COMPONENT LAYOUT
Remote control (fi g 1)
1. LCD display
2. (ON)
3. (OFF)
4. Number/letter keys
5. Channel (CH)
6. Group (GRP)
7. Brighter/Menu selection (UP)
8. Darker/Menu selection (DOWN)
9. (SET)
10. Programming (PROG)
11. Brightness level (LEV)
12. Function
Dimmer receiver (fi g 2)
1. LCD display
2. (RESET)
3. Brighter (UP)
4. On/Off
On/off receiver (fi g 3)
1. LCD display.
2. (RESET)
3. (ON/OFF)
4. Mains connection (MAIN)
5. (OUTPUT)

IKEA koppla Specifications

General

Brand	IKEA
Model	koppla
Category	Battery Charger
Language	English
