6 Installation
Installation and Programming manual
Chapter 2
INSTALLATION
The Ivy unit should be mounted high up on a smooth surface, in
such a way that it is out of reach but on view and, therefore, may
serve as a visible deterrent against break-in.
2-1Installation guidelines
1. Remove all electrical power.
2. Open the bottom-hinged casing (Table 4, U).
3. Remove the metal guard (Table 4, V).
4. Pull the connection wires through the cable entry (Table 4, L).
5. Using the wall plugs, attach the plastic backplate to the wall
(Table 4, M). The wall plug locations are clearly marked on the
drilling-pattern (included).
6. Insert the tamper-protection screw into its location (
Table 4, N
).
7. Locate the battery in its housing (Table 4, D), then connect it
by means of the battery wires (Table 4, E). Ensure that the
battery polarity is correct.
8. Complete the device wiring. During this phase, the STATUS
LED will blink at 1 second intervals.
9. Configure the device.
Note
If the factory default settings suit the installation requirements, device
configuration will be unnecessary.
10. Replace the metal guard and the plastic casing. The STATUS
LED will blink at 0.5 second intervals.
11. Powerup the device. The STATUS LED will go On (solid) for 10
seconds. The LED will go Off when the Ivy unit enters the ope-
rating phase (standby).
2-2Battery connections
This device requires a 12V, 2.1Ah battery (not included) which must
be connected by means of the respective wires (Table 4, E). Take
care to respect the battery polarity during the installation phase
(red=positive; black=negative).
The battery-efficiency test will run 60 minutes after installation and
every 10 minutes thereafter. In the event of an alarm, the battery
test will be delayed by 60 minutes.
Failure of the battery-efficiency test will generate the respective
signal (Table 6, Inefficient battery). If the battery voltage drops
below 11V during an alarm event, the horn will deactivate
automatically, however, all other signaling will continue until the
voltage drops below 10V. All functions will be re-established when
the battery voltage restores to 12V.
