Inovance Easy320 User Manual

‑15‑
No. Terminal
Type
Terminal
Code
Assignment Indicator
color
Description
⑤/‑
⑥
Extension
card slot
EXP‑A/EXP‑B Function
extension
‑ For details of extension card
options, see "
Appendix:
Extension Card Options
" on
page 38
.
⑦ RS485
485+ RS485
communica‑
tion signal+
‑ ‑
485‑ RS485
communica‑
tion signal‑
‑ ‑
GND RS485
communica‑
tion GND
‑ ‑
⑧
Power
supply
interface
+24V 24 VDC power
supply (+)
‑ ‑
0V 24 VDC power
supply (‑)
‑ ‑
PE ‑ ‑
⑨
I/O terminal
– 8 inputs and
8 outputs
‑ See details in "
3.1 Layout of
Terminals
" on page 29 .
⑩/‑
⑪
Ethernet
port
EtherNET1/
EtherNET2
RJ45
interface
‑ ‑
