‑17‑
Item Specifications
Extension
card
Supports up to two extension cards.
Program
language
LD, SFC, FB/FC function (LD) supported
Type‑C Supports user program download/upload and firmware upgrade through
type‑C or GE20–TF extension card.
IP rating IP20
Dimensions
(W x H x D)
53 mm x 100 mm x 80 mm
Weight About 184 g
1.3.2 Power Supply Specifications
Item Specifications
Rated voltage of terminal input power
supply
24 VDC±10% (21.6 VDC to 26.4 VDC)
Rated current of terminal input power
supply
1 A (maximum value at 24 V)
24 V input power supply protection Providing protection against short circuit
and reverse connection
Hot‑plugging Not supported
1.3.3 Input Specifications
Item Specifications
Input type Digital input
Number of input channels 8
Input mode SINK/SOURCE
Input voltage class 24 VDC±10% (21.6 VDC to 26.4 VDC)
