Inovance Easy521 User Manual

‑19‑
Item Specifications
Software filter time
● Low‑speed: 2 ms to 1000 ms
● High speed: 2 μs to 1000 μs
Isolation mode Isolated by digital isolator chip
Common terminal mode 8‑point/common terminal (The polarity +/‑ of
input power supply is changeable.)
Input action display The input indicator lights up (controlled by
software) when the input is in drive state.
1.3.4 Output Specifications
Item Specifications
Output type Transistor NPN
Number of output channels 8
Output voltage class 24 VDC±10% (21.6 VDC to 26.4 VDC)
High‑speed
output
(Y0 to Y7)
Output load
(resistive load)
0.5 A/point; 2 A/8‑point
Output load
(inductive load)
7.2 W/point; 24 W/8‑point
Output load
(lamp load)
5 W/point, 18 W/8‑point
Hardware
response time
ON/OFF
< 1 us (OFF→ON); < 2 us (ON→OFF)
Load current
requirements
Load current ≥ 12 mA when used with outputs greater
than 10 kHz
Max. output
frequency
200 kHz for resistive load; 0.5 Hz for inductive load; 10 Hz
for lamp load
Leakage current at OFF Less than 30 uA at 24 V
Max. residual voltage during
ON
Less than 0.5 VDC
Isolation mode Digital isolator
Common terminal mode 8‑point/common terminal (“‑” of power supply)
