‑11‑
Item Specification
Current output accuracy (full temperature
range)
±0.5% (full range)
Current output diagnosis Supports open circuit detection,
overtemperature protection
Isolation No isolation between the channels;
Isolation between the channels and the
power supply;
Isolation between the channels and the bus
Output action display N/A
Output derating N/A
■ Software specifications
Item Specification
Independent channel enable
configuration
Supported
Diagnostic report configuration Supported
Diagnostic detection configuration Short circuit detection and wire break detection, not
supported by output range containing 0
Conversion mode configuration ±10 V, 0 to 10 V, ±5 V, 0 to 5 V, 1 to 5 V, 0 to 20 mA, 4
to 20 mA
Output after stop configuration Output zero, output last value, output preset value
Preset value configuration Supported
Digital output range configuration The default is consistent with that of GL10 (–20000 to
20000) and supports ±32000
Sampling time 250 us for four channels
Sampling refresh Refresh asynchronously according to the sampling
time, not required to refresh synchronously
according to the bus cycle
When in stop mode Output according to output mode upon stop and
present value, no refresh
