Inovance MDKE9 Series User Manual

3 Installation and Wiring
- 15 -
3
3） Take the MDKE9 out.
Press clip
2
in gure 3-5 with the index nger and middle nger to release the MDKE9, then pull the
upper end of the MDKE9 out of the base slot.
Figure 3-6 Sheet metal slot dimensions Figure 3-7 Base mounting hole size
4
-φ5
79
70
53.3
68
77.2
94.4
108.5
68
72.8
80
80
79
40
Unit: mm
46.
846.8
27.5
27.5
47 47
84.8
90
117.2
