Wireless Indicators
Table –1 Wireless Indicators
Category
Parameter
Specifications
2.4G
WIFI
RF output power
(ERP/EIRP)
13–17 dBm
Frequency band
(MHz)
2412–2472 (center frequency)
Modulation DSSS, OFDM
GSM
RF output power
(ERP/EIRP)
GSM900: 33 dBm ± 2 dB
GSM1800: 30 dBm ± 2 dB
Frequency band
(MHz)
EGSM900: 880–915 MHz (TX), 925–960 MHz (RX)
DCS1800: 1710–1785 MHz (TX), 1805–1880 MHz (RX)
Modulation GMSK for GSM/GPRS, GMSK and 8PSK for EDGE
WCDMA
RF output power
(ERP/EIRP)
WCDMA: 24 dBm + 1/‑3 dB
Frequency band
(MHz)
WCDMA Band I: 1920‑1980 MHz (TX), 2110‑2170 MHz (RX)
WCDMA Band VIII: 880–915 MHz (TX), 925–960 MHz (RX)
Modulation WCDMA: QPSK
HSDPA: QPSK/16QAM
HSUPA: BPSK
LTE
RF output power
(ERP/EIRP)
LTE FDD: 23 dBm ± 2 dB
LTE TDD: 23 dBm ± 2 dB
Frequency band
(MHz)
FDD LTE Band 1: 1920‑1980 MHz (TX), 2110‑2170 MHz (RX)
FDD LTE Band 3: 1710‑1785 MHz (TX), 1805‑1880 MHz (RX)
FDD LTE Band 7: 2500‑2570 MHz (TX), 2620‑2690 MHz (RX)
FDD LTE Band 8: 880–915 MHz (TX), 925–960 MHz (RX)
FDD LTE Band 20: 832‑862 MHz (TX), 791‑821 MHz (RX)
FDD LTE Band 28: 703‑748 MHz (TX), 758‑803 MHz (RX)
FDD LTE Band 38: 2570‑2620 MHz (TX), 2570‑2620 MHz (RX)
FDD LTE Band 40: 2300‑2400 MHz (TX), 2300‑2400 MHz (RX)
Modulation QPSK/16QAM
