15
61-Bottle Built-In Wine Cooler
www.insigniaproducts.com
10 Use a thin, flat blade screwdriver or knife blade to remove door pivot
sleeve from the top of the door, then take the new door pivot sleeve
from the hardware bag and install it on the bottom of the door in the
hole provided.
11 Remove the decorative screws from the top of the door, then take the
new decorative screws from the hardware bag contents and install
them in the bottom of the door.
12 Remove the screws securing the top right hinge to the cooler, then
remove the hinge.
WARNING: Be extremely careful when using a screwdriver or knife blade so that
you don’t cut your hand or fingers, or otherwise injure yourself.
Top of door
Door pivot sleeve
Decorative screws
Top of door
Top right hinge
Hinge screws
