Intel D34010WYB User Manual

Intel NUC Board D54250WYB and Intel NUC Board D34010WYB
Technical Product Specification
50
Table 22 lists the settings for the jumper.
Table 22. BIOS Security Jumper Settings
Function/Mode Jumper Setting Configuration
Normal 1-2 The BIOS uses current configuration information and passwords
for booting.
Lockdown 2-3 The BIOS uses current configuration information and passwords
for booting, except:
• All POST Hotkeys are suppressed (prompts are not displayed
and keys are not accepted. For example, F2 for Setup, F10
for the Boot Menu).
• Power Button Menu (see Section 3.7.4)
BIOS updates are not available except for automatic Recovery
due to flash corruption.
Configuration
Mode
None BIOS Recovery Update process if a matching *.bio file is found.
Recovery Update can be cancelled by pressing the Esc key.
If the Recovery Update was cancelled or a matching *.bio file
was not found, a Config Menu will be displayed. The Config
Menu consists of the following (followed by the Power Button
Menu selections):
[1] Suppress this menu until the BIOS Security Jumper is
replaced.
[2] Clear BIOS User and Supervisor Passwords.
[3] Reset Intel AMT to default factory settings.
[4] Clear Trusted Platform Module.
For information on the Power Button Menu, see Section 3.7.4.
