Using the BIOS Setup Program
59
ATA/IDE Configuration Submenu
Main Advanced Security Power Boot Exit
IDE Configuration
ATA/IDE Configuration [Legacy]
Legacy IDE Channels [PATA Pri and Sec]
PCI IDE Bus Master [Enabled]
Hard Disk Pre-Delay [Disabled]
xxxxxxx]
[PATA Primary Slave :
Not Detected]
[PATA Secondary Master :
xxxxxxx]
[PATA Secondary Master :
Xxxxxxx]
Select Screen
Select Item
Enter
Select
Sub-Menu
F1 General Help
P9 Setup Defaults
F10 Save and Exit
ESC Exit
This submenu shown in Table 17 is used to configure IDE device options.
Table 17. ATA/IDE Configuration Submenu
Feature Options Description
ATA/IDE Configuration • Disabled
• Legacy
• Enhanced (default)
Specifies the integrated IDE controller.
Disabled disables the integrated IDE controller.
Legacy enables up to two IDE channels for OS
requiring legacy IDE operation.
Enhanced all SATA and PATA resources.
Legacy IDE Channels • PATA Pri only
• PATA Sec only
• PATA Pri and Sec (default)
• SATA P0/P1 only
• SATA P0/P1, PATA Sec
• SATA P0/P1, PATA Pri
Configures PATA and SATA resources for OS
requiring legacy IDE operation.
PCI IDE Bus Master • Disabled
• Enabled (default)
Allows a PCI device to initiate a transaction as
a master.
Hard Disk Pre-Delay
• Disabled (default)
• 3 Seconds
• 6 Seconds
• 9 Seconds
• 12 Seconds
• 15 Seconds
• 21 Seconds
• 30 Seconds
Specifies the hard disk drive pre-delay. Causes
the BIOS to insert a delay before attempting to
detect IDE drives in the system.
NOTE: SATA hard drives are not supported on desktop board D865GVHZ.
