Intel DH61BF User Manual

Intel Desktop Board DH61BF Technical Product Specification
14
Table 2. Components Shown in Figure 1
Item/callout
from Figure 1 Description
A PCI Express 2.0 x1 bus add-in card connector
B PCI Express 2.0 x1 bus add-in card connector
C PCI Express 3.0 x16 bus add-in card connector
D Rear chassis fan header
E Back panel connectors
F 12 V processor core voltage connector (2 X 2)
G LGA1155 processor socket
H Processor fan header
I DIMM 1 (Channel A DIMM 1)
J DIMM 2 (Channel B DIMM 1)
K Main power connector (2 x 12)
L Battery
M BIOS setup configuration jumper block
N SATA connectors
O Front panel header
P Front panel USB 2.0 header
Q Intel H61 Express Chipset
R Front panel USB 2.0 header
S Serial port header
T Front panel audio header

Intel DH61BF Specifications

General

Form Factor	microATX
Chipset	Intel H61
Socket	LGA 1155
Memory Type	DDR3
Memory Slots	2
Max Memory	16 GB
PCIe Slots	1 x PCIe 3.0 x16, 2 x PCIe 2.0 x1
USB Ports	4 x USB 2.0
SATA Ports	4
Video Outputs	VGA, DVI-D
BIOS	UEFI
