Intel DH61BF User Manual

Product Description
27
1.14 Platform Management and Security
Intel DH61BF Desktop Board integrates several functions designed to manage the
system and lower the total cost of ownership (TCO) of the system. These system
management functions are designed to report errors, diagnose the system, and
recover from system lockups without the aid of an external microcontroller.
1.14.1 Hardware Management Subsystem
The hardware management features enable the board to be compatible with the Wired
for Management (WfM) specification. The board has several hardware management
features, including the following:
• Fan monitoring and control
• Thermal and voltage monitoring
1.14.2 Hardware Monitoring
The hardware monitoring and fan control subsystem is based on the ITE 8728F device,
which supports the following:
• Processor and system ambient temperature monitoring
• Chassis fan speed monitoring
• Power monitoring of +12 V, +5 V, +3.3 V, V_SM, and +VCCP
• SMBus interface
1.14.2.1 Fan Monitoring
Fan monitoring can be observed through the BIOS setup user interface, Intel
®
Desktop
Utilities, or third-party software.
For information about
Refer to
The functions of the fan headers Section 1.15.2.2, page 32

Intel DH61BF Specifications

General

Form Factor	microATX
Chipset	Intel H61
Socket	LGA 1155
Memory Type	DDR3
Memory Slots	2
Max Memory	16 GB
PCIe Slots	1 x PCIe 3.0 x16, 2 x PCIe 2.0 x1
USB Ports	4 x USB 2.0
SATA Ports	4
Video Outputs	VGA, DVI-D
BIOS	UEFI
