Intellian v150NX User Manual

12
Planning Installation
ACU Box (Including Components Kit)
Before beginning installation, make sure you have all the included components.
Description Q'ty Size Remarks
Antenna Control Unit (ACU) 1
431 mm x 350 mm x
44.3 mm
Antenna Control Unit (ACU)
Quick Installation Guide (QIG) 1
RF Hazard Sticker 1 Radiation Safety Distance (15 m) Label
Mounting Template 1
ACU Rack Mount Bracket 2 To x ACU to 19 inch Rack Frame
Flat Head Screw 10 M4 x 12L Bolt Kit for Rack Type Mount Bracket
USB Cable (A-A) 1 1.8 m ACU (Front Panel) to PC
AC Power Cord (CEEE7/7) 1 1.5 m ACU Power (220 V)
RG-6 RF Cable 2 1 m ACU to Modem
Modem Interface Cable
(For iDirect Modem)
1 1.5 m ACU to Modem (iDirect Modem)
Ethernet Cable (RJ45/LAN) 2 1 m ACU to PC/Intellian M&C
Wi-Fi Dongle 1
Hex Bolt (BUMAX) 5 M12 x 80L
Bolt Kit for Antenna-Deck (Mast)
Assembly (1 spare set included)
Flat Washer (BUMAX) 5 M12
Spring Washer (BUMAX) 5 M12
Hex Head Wrench Bolt 5 M6 x 40L
Bolt Kit for Radome Assembly
Spring Washer and Flat Washer 5 M6
Cable Tie 50 140 mm For Fixing Cables
Loctite 263 1 10 ml
